G0603X 25" Extreme Series Planer
-25-
Power Controls
Table adjustments can be made with the power/
table controls, or in conjunction with the digital
control.
The digital control adds these convenient fea
-
tures:
• Move the table to a one-time preset position.
• Add or subtract distance from the current
table position.
• Move the table to one of ten preset locations
stored in digital memory.
There are two LED readouts on the digital con
-
trol. The top LED shows the target position value
intended for the table, if one is entered, and the
bottom LED shows the actual position of the
table.
The readout values can be expressed either in
millimeters or inches with the use of the MM/INCH
key
. The corresponding LED light on this key
will show which measurement is active.
To move the table with the power/table con
-
trols only:
1. Press the TABLE UP or TABLE DOWN but-
ton on the power/table control.
2. Table movement will stop when the button is
released.
The digital control has two modes of operation—
manual and single.
In MANUAL mode, the table can be moved either
with the power/table control buttons or the digital
control keypad.
To use the digital control keypad in manual
mode to move the table:
1. Press the MANUAL/SINGLE key
to
select MANUAL mode—the light on this key
will blink.
• Press the “9” key
on the digital key-
pad to move the table up.
• Press the “8” key
on the digital key-
pad to move the table down.
2. Release the key to stop table movement.
The SINGLE mode of the digital control provides
precise movement of the table to a preset posi
-
tion.
To move the table to a one-time preset posi
-
tion:
1. On the digital keypad, press the MANUAL/
SINGLE key
to select SINGLE mode—
the light on this key will be off.
2. Press the PROGRAM key
—an LED will
blink in the top target window.
3. Using the numerical keypad, enter the target
value for the table position.
4. Press the ENTER key
—the light on the
START key
will blink.
5. Press the START key
to send the table
to the target position.
Note: To cancel the table movement before it has
reached the target value, press the STOP key
. To restart the procedure, you will have to re-
enter the target value again.
