G0603X 25" Extreme Series Planer
-47-
Figure 48. Cutterhead/feed motor junction box.
Figure 47. Digital control (viewed from back). Figure 50. Power/table control (viewed from
back).
Figure 51. Table motor junction box.
Figure 52. Power feed
junction box.
Figure 49. Headstock cover
limit switch (top right access
panel removed).
Figure 53
. Upper and lower
table limit switches, and table
height magnetic reader (top
right access panel removed).
Lower Limit
Switch
Magnetic
Reader
Upper Limit
Switch
To Next Page
