Grizzly G0645 - Parts List; Label Placement

G0645 Benchtop Mortising Machine
-29-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0645001 MOTOR 1/2 HP 110V 34 PB07M HEX BOLT M8-1.25 X 25
1-1 P0645001-1 FAN COVER 35 PW01M FLAT WASHER 8MM
1-2 P0645001-2 FAN 36 PSS09M SET SCREW M8-1.25 X 20
1-3 P0645001-3 CAPACITOR COVER 37 P0645037 GEAR
1-4 P0645001-4 R CAPACITOR 30M 250V 2-7/8 X 1-3/8 38 P0645038 FENCE ADJUSTMENT KNOB
2 P0645002 CHUCK JT#2 0-3/8" 39 P0645039 RACK
3 P0645003 CHUCK KEY/HEX WRENCH 4MM 40 PSB28M CAP SCREW M6-1 X 15
4 P0645004 LOCK LEVER M8-1.25 X 20 41 P0645041 ALIGNMENT PIN
5 PS07M PHLP HD SCR M4-.7 X 8 42 P0645042 BALL END
6 P0645006 CHUCK ACCESS COVER 44 P0645044 GAS SPRING ASSEMBLY
7 PSS09M SET SCREW M8-1.25 X 20 44-1 P0645044-1 CYLINDER
8 P0645008 BUSHING 44-2 P0645044-2 COLUMN ADAPTER
9 P0645009 DEPTH STOP ROD 46 P0645046 LOCK LEVER M8-1.25 X 50
10 P0645010 HEADSTOCK 47 PW01M FLAT WASHER 8MM
11 P0645011 DOVETAIL GIB 50 P0645050 RACK
12 PSB14M CAP SCREW M8-1.25 X 20 51 P0645051 BRACKET
13 PS39M PHLP HD SCR M8-1.25 X 10 52 PSS16M SET SCREW M8-1.25 X 10
14 P0645014 GEAR 53 PSS09M SET SCREW M8-1.25 X 20
15 P0645015 SPECIAL SCREW 54 P0645054 FENCE
16 P0645016 SPACER 55 PSS16M SET SCREW M8-1.25 X 10
17 P0645017 SHAFT 56 P0645056 HOLD DOWN ROD
18 PRP08M ROLL PIN 6 X 30 57 P0645057 HOLD DOWN
19 P0645019 CLUTCH 58 P0645058 LOCK LEVER M8-1.25 X 20
20 P0645020 CLUTCH COLLAR 59 P0645059 BASE
21 P0645021 COMPRESSION SPRING 60 PSN03M SQUARE NUT M8-1.25
22 P0645022 SHOULDER BOLT M10-1.5 X 15 61 P0645061 EXTENSION BLOCK
23 PRP07M ROLL PIN 6 X 20 62 PB82M HEX BOLT M8-1.25 X 80
24 P0645024 HANDLE 65 P0645065 POWER CORD 18AWG X 3C
25 P0645025 RUBBER GRIP 66 P0645066 T-HANDLE HEX WRENCH 4MM
27 P0645027 MAGNET 67 PEC07M E-CLIP 7MM
28 PSB24M CAP SCREW M5-.8 X 16 68 P0645068 SWITCH COVER
30 PS11M PHLP HD SCR M6-1 X 16 69 P0645069 SWITCH
32 P0645032 TOOL STORAGE RACK 70 PHTEK31M TAP SCREW M4 X 14
33 P0645033 COLUMN ASSEMBLY 71 P0645071 STRAIN RELIEF
Parts List
Label Placement
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
REF PART # DESCRIPTION REF PART # DESCRIPTION
100 P0645100 ID LABEL 104 PLABEL-14 ELECTRICITY LABEL
101 P0645101 SAFETY GLASSES LABEL 2-3/4" X 1-1/2" 105 P0645105 HAND INJURY LABEL 1-1/2" X 2-1/2"
102 P0645102 READ MANUAL LABEL 1-1/2" X 2-1/2" 106 PPAINT-1 GRIZZLY GREEN TOUCH UP PAINT
103 P0645103 DISCONN POWER LABEL 1-1/2" X 2-1/2"
