Table Travel
The table travels in two directions and is con-
trolled by handwheels, as illustrated in Figure 23:
• X-axis (longitudinal)
• Y-axis (cross)
X-Axis or Longitudinal Travel
(Left & Right)
Y-Axis or
Cross Travel
(In & Out)
Figure 23. Possible directions of table travel.
Graduated Dials
The handwheels have graduated dials that are
used to determine table movement in 0.001" incre-
ments, with one full revolution equalling 0.100".
Rotate graduated dial to a relative starting point
(see Figure 24).
Figure 24. Graduated dial location.
Graduated Dial
X-Axis Handwheel
Tool Needed Qty
Hex Wrench 5mm .............................................. 1
To use X-axis handwheel:
1. Loosen both X-axis table locks shown in
Figure 25.
Note: To readjust positioning of table locks,
pull out and rotate.
2. Position table stops along front of table to
restrict table travel.
3. Adjust X-axis graduated dial to zero, then use
handwheel to move table.
Y-Axis Handwheel
The saddle does not have limit stops. To move
the table along the Y-axis, loosen the Y-axis
table locks shown in Figure 25, then use the
handwheel in front of the table in the same man-
ner as the X-axis handwheel.
Figure 25. X- and Y-axis table travel locks.
X-Axis
Table Locks
Y-Axis
Table Locks
Table Stops
