Model G0758 (Mfd. Since 2/14)
-37-
READ ELECTRICAL SAFETY
ON PAGE 36!
G0758 Wiring Overview
Figure 49. Wiring overview.
Front Panel
Motor
Spindle
RPM
Sensor
Figure 50. Wiring overview.
Side Panel
Front Panel
Inside
Bottom
Panel
Limit Switch
Rear Panel
