Model G0758 (Mfd. Since 2/14)
-5-
The information contained herein is deemed accurate as of 5/20/2014 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2Model G0758
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0758 MILL/DRILL
Product Dimensions:
Weight.............................................................................................................................................................. 161 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................ 19-3/4 x 25-1/2 x 30-1/4 in.
Footprint (Length x Width)............................................................................................................... 16-1/2 x 15-3/4 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 176 lbs.
Length x Width x Height....................................................................................................................... 24 x 22 x 32 in.
Electrical:
Power Requirement........................................................................................................... 110V, Single-Phase, 60 Hz
Full-Load Current Rating.......................................................................................................................................... 8A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 5 ft.
Power Cord Gauge......................................................................................................................................... 16 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 5-15
Switch Type........................................................................................... ON/OFF Push Button Switch w/Safety Cover
Motors:
Main
Type......................................................................................................................................... High-Torque DC
Horsepower................................................................................................................................ 600W (3/4 HP)
Phase............................................................................................................................................ Single-Phase
Amps.............................................................................................................................................................. 8A
Speed................................................................................................................................................ 4500 RPM
Power Transfer ................................................................................................................................. Gear Drive
Bearings....................................................................................................... Shielded and Permanently Sealed
Main Specifications:
Operation Info
Spindle Travel.............................................................................................................................................. 2 in.
Max Distance Spindle to Column.......................................................................................................... 6-5/8 in.
Max Distance Spindle to Table.................................................................................................................... 9 in.
Longitudinal Table Travel (X-Axis)............................................................................................................. 13 in.
Cross Table Travel (Y-Axis).................................................................................................................. 5-1/2 in.
Vertical Head Travel (Z-Axis)................................................................................................................ 8-1/4 in.
Head Tilt (Left/Right)........................................................................................................ Left 45, Right 45 deg.
Drilling Capacity for Cast Iron................................................................................................................... 5/8 in.
Drilling Capacity for Steel......................................................................................................................... 1/2 in.
End Milling Capacity................................................................................................................................. 5/8 in.
Face Milling Capacity................................................................................................................................... 2 in.
