Grizzly G0758 User Manual

-38-
Model G0758 (Mfd. Since 2/14)
READ ELECTRICAL SAFETY
ON PAGE 36!
23 24
13 14
WX14-12
4 K7±5
ZD-SK-THL
L2
L1
A+
A
P3
P1
R31
5WR02J
B
A
J2 J1
IN IN
N
N1
L1
G
L
CESX 1101-28
JD-014 REV A 091111
Neutral
Hot
Ground
110 VAC
5-15 Plug
(As Recommended)
To Plug
Fuse - F10AL250V
Fuse Holder - MF528 10A 250V
Fuse - F10AL250V
Fuse Holder - MF528 10A 250V
Variable
Speed Dial
GND
KEDU
KJD17B
120V
Front Panel (Viewed From Behind) Side Panel Rear Panel
Inside Bottom Panel
110V Motor
Spindle
RPM
Sensor
On/Off Switch
Spindle Speed DRO
Circuit Board
Circuit Board
Limit Switch
KW1-103
15A 125VAC
16(4)A 250 VAC
JYMC- 22UB-II
DC Motor Speed Control
G0758 Wiring
