Grizzly G0758 User Manual

Model G0758 (Mfd. Since 2/14)
-41-
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call (800) 523-4777 or visit our online parts store at www.grizzly.com to check for availability.
Column
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0758001 Z-AXIS SLIDE 35 P0758035 SHOULDER SCREW M6-1 X 60, 10
2 P0758002 SET SCREW M6-1 X 16 36 P0758036 Z-AXIS GRADUATED DIAL
3 P0758003 FLAT WASHER 8MM 38 P0758038 HANDWHEEL CURVED PLATE SPRING
4 P0758004 LOCK WASHER 8MM 40 P0758040 HEX NUT M8-1.25
5 P0758005 CAP SCREW M8-1.25 X 25 44 P0758044 KEY 4 X 4 X 12
6 P0758006 FLAT WASHER 12MM 48 P0758048 COLUMN
7 P0758007 LOCK WASHER 12MM 49 P0758049 Z-AXIS SCALE
8 P0758008 CAP SCREW M12-1.75 X 40 50 P0758050 THREADED SLEEVE M6-1 X 16
9 P0758009 T-BOLT M8-1.25 X 60 51 P0758051 CAP SCREW M6-1 X 14
10 P0758010 FLAT WASHER 8MM 52 P0758052 X-AXIS LEADSCREW BRACKET (LH)
11 P0758011 LOCK WASHER 8MM 54 P0758054 TABLE
12 P0758012 HEX NUT M8-1.25 55 P0758055 COOLANT HOSE FITTING
13 P0758013 SLIDE ALIGNMENT BLOCK 56 P0758056 X-AXIS LEADSCREW BRACKET (RH)
14 P0758014 LOCK PLUNGER, BRASS 57 P0758057 TABLE HANDWHEEL HANDLE M6-1 X 10
15 P0758015 ADJUSTABLE HANDLE M8-1.25 X 20 58 P0758058 TABLE HANDWHEEL
16 P0758016 GIB ADJUSTMENT SCREW 59 P0758059 TABLE GRADUATED DIAL
17 P0758017 Z-AXIS GIB 60 P0758060 THRUST BEARING 51100
18 P0758018 HEADSTOCK ANGLE SCALE 61 P0758061 CAP SCREW M6-1 X 10
19 P0758019 CAP SCREW M5-.8 X 10 62 P0758062 LIMIT STOP
20 P0758020 Z-AXIS WAY COVER 63 P0758063 T-NUT M6-1
21 P0758021 HEX NUT M5-.8 64 P0758064 X-AXIS SCALE
22 P0758022 Z-AXIS WAY COVER BRACKET 65 P0758065 X-AXIS LEADSCREW
23 P0758023 Y-AXIS WAY COVER 66 P0758066 X-AXIS LEADSCREW NUT
24 P0758024 Y-AXIS WAY COVER BRACKET 67 P0758067 CAP SCREW M4-.7 X 20
25 P0758025 HEX NUT M16-1.5 68 P0758068 SADDLE
26 P0758026 THRUST BEARING 51200 69 P0758069 TABLE STOP BLOCK
27 P0758027 HANDWHEEL CURVED PLATE SPRING 70 P0758070 Y-AXIS GIB
28 P0758028 KEY 4 X 4 X 16 71 P0758071 Y-AXIS LEADSCREW NUT
29 P0758029 Z-AXIS LEADSCREW 72 P0758072 X-AXIS GIB
30 P0758030 Z-AXIS LEADSCREW NUT 73 P0758073 CAP SCREW M6-1 X 25
31 P0758031 Z-AXIS HANDWHEEL 74 P0758074 X-AXIS BEARING HOUSING
32 P0758032 HANDWHEEL HANDLE M6-1 X 10 75 P0758075 X-AXIS LEADSCREW
33 P0758033 CAP SCREW M8-1.25 X 30 76 P0758076 BASE
34 P0758034 COLUMN TOP COVER 77 P0758077 CAP SCREW M12-1.75 X 90
