Model G0771 (Mfd. Since 8/15)
-3-
Identification
Figure 1. Model G0771 identification of main controls and components.
Left
Extension
Wing
For Your Own Safety Read Instruction
Manual Before Operating Saw
a) Wear eye protection.
b) Use saw-blade guard and spreader for
every operation for which it can be used,
including all through sawing.
c) Keep hands out of the line of saw blade.
d) Use a push-stick when required.
e) Pay particular attention to instructions
on reducing risk of kickback.
f) Do not perform any operation freehand.
g) Never reach around or over saw blade.
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
Miter
Gauge
Blade
Guard
Fence
Right
Extension
Wing
Scale
Front
Fence
Rail
Blade Tilt
Handwheel
Blade
Tilt
Lock
4" Dust
Port
Fence
Lock
Handle
Blade Tilt
Scale
Blade Height
Handwheel
Blade
Height Lock
Rear
Fence
Rail
ON/OFF
Switch
