Grizzly G0771 - Miter Gauge Parts

Model G0771 (Mfd. Since 8/15)
-77-
Miter Gauge
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P0771501 FLAT PLATE 513 P0771513 RIVET
502 P0771502 SPRING PLATE COVER 514 P0771514 MITER PIN
503 P0771503 MITER GAUGE BODY 515 P0771515 FLAT HD SCR 4-40 X 3/16
504 P0771504 MITER BAR 516 P0771516 SET SCREW 10-24 X 1/2
505 P0771505 ANGLE INDICATOR 517 P0771517 THREADED STOP PIN
506 P0771506 UPPER HANDLE CAP 518 P0771518 FLAT WASHER 3MM
507 P0771507 LOWER HANDLE CAP 519 P0771519 PHLP HD SCR 10-32 X 1/4
508 P0771508 CAP SCREW M8-1.25 X 50 520 P0771520 PHLP HD SCR 6-32 X 7/16
509 P0771509 HANDLE WASHER 6 X 20 521 P0771521 FLAT HD SCR 1/4-28 X 5/16
510 P0771510 MITER SCALE 522 P0771522 SET SCREW 10-32 X 1/4
511 P0771511 SPRING PLATE 523 P0771523 MITER BAR GUIDE WASHER
512 P0771512 MITER HANDLE
