Grizzly G0815 User Manual

Model G0815 (Mfd. Since 09/18)
-45-
READ ELECTRICAL SAFETY
ON PAGE 44!
Wiring Diagram
GND
Motor
Start Capacitor
CD60
600MFD
125VAC
A
RESET
96
98
T1/2 T3/6 8T2/4
L1/1 L3/5
7
L2/3
95
12
15
18
SET @ 14A
GND
1/2 3/4 5/6
Relay RA-20
Contactor
SDE MA-15
220V-240V
Magnetic Switch
Hot
Hot
Ground
6-20 Plug
220
VAC
G
Figure 61. Magnetic switch with cover
removed.
Figure 62. Motor wiring.
