-50-
Model G0815 (Mfd. Since 09/18)
Labels & Cosmetics
301
301
302V2
304
INJURY HAZARD!
To reduce the risk of serious personal
injury, do not remove this cover while the
machine is running or connected to power.
Always disconnect power before servicing.
D
o
w
n
U
p
305
306
307
308
311
312
313
309
Fluid Capacities
4 Oz.
Gearbox Grizzly #T26685 or ISO 32 Equivalent
Component TypeCapacity
Check the oil level in
the gear box before
operating machine.
Refer to the manual
for instructions.
Only shift gearbox when
planer is running.
Neutral
30 FPM
16 FPM
INJURY HAZARD!
To reduce risk of short
and long-term injury,
wear safety glasses,
hearing protection, and
a respirator when using
this machine.
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
WARNING!
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
MODEL G0815
15" HEAVY-DUTY PLANER
Motor: 3 HP, 240V, 60 Hz, 14A
Max. Depth of Cut Per Pass: 1/8"
Min. Stock Thickness: 1/4"
Min. Stock Length: 6-3/8"
Max. Stock Thickness: 8-1/4"
Max. Cutting Width: 15"
Feed Rate: 16, 30 FPM
Cutterhead Speed: 5000 RPM
Cutterhead: 3" Dia., 3-Knife
Weight: 350 lbs.
Specifications
WARNING!
To reduce the risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses and respirator.
3. Disconnect power before doing any service on machine.
4. Only plug power cord into a grounded outlet.
5. Do not wear loose clothing, gloves, jewelry, or items that can get
entangled. Tie back long hair and roll up sleeves.
6. Ensure machine is correctly set up before starting.
7. Never cut deeper than 1/8" on a single pass.
8. Never plane material smaller than 8" long, 3/4" wide, or 1/4" thick.
9. Do not allow hands or clothing to get pulled into cutting area
while feeding workpiece.
10. Stand clear of board ends during cutting operation.
11. Do not plane boards with cracks, loose knots, or other defects.
12. Knives are sharp! Use extreme caution when changing/adjusting.
13. Never reach into cutting area during machine operation.
14. Prevent unauthorized use by children or untrained users.
Mfd. for Grizzly in Taiwan
Date
S/N
177335
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P0815301 ELECTRICITY LABEL 308 P0815308 EYE/EAR/LUNG INJURY WARNING LABEL
302V2 P0815302V2 MACHINE ID LABEL V2.09.18 309 P0815309 TOUCH-UP PAINT, GRIZZLY GREEN
303 P0815303 DO NOT OPEN COVER LABEL 310 P0815310 MODEL NUMBER LABEL
304 P0815304 HANDWHEEL ROTATION LABEL 311 P0815311 GRIZZLY.COM LABEL
305 P0815305 FLUID CAPACITY LABEL 312 P0815312 READ MANUAL LABEL
306 P0815306 CHECK OIL NOTICE LABEL 313 P0815313 DISCONNECT POWER LABEL
307 P0815307 FEED SPEED SHIFT WARNING LABEL
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
