Grizzly G0815 User Manual

Model G0815 (Mfd. Since 09/18)
-47-
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0815001 MOTOR 3HP 220V 1-PH 44 P0815044 FLAT WASHER 3/4
1-1 P0815001-1 MOTOR FAN COVER 45 P0815045 COMPRESSION SPRING 3.5 X 19 X 70
1-2 P0815001-2 CAPACITOR COVER 46 P0815046 BUSHING BLOCK
1-3 P0815001-3 MOTOR JUNCTION BOX 47 P0815047 ROLLER ADJUSTMENT PLATE
1-4 P0815001-4 MOTOR FAN 48 P0815048 HEX NUT 1/4-20
1-5 P0815001-5 S CAPACITOR 600M 125V 1-3/4 X 3-3/8 49 P0815049 OUTFEED ROLLER
1-6 P0815001-6 MOTOR BEARING 6205ZZ (FRONT) 50 P0815050 DEPTH LIMITER
1-7 P0815001-7 MOTOR BEARING 6203ZZ (REAR) 51 P0815051 FLAT HD SCR 1/4-20 X 5/16
1-8 P0815001-8 CONTACT PLATE 52 P0815052 KEY 5 X 5 X 20
1-9 P0815001-9 CENTRIFUGAL SWITCH 54 P0815054 SPROCKET 27T
2 P0815002 MOTOR CORD 12G 3W 20" 56 P0815056 HEX BOLT 1/4-20 X 5/8
3 P0815003 FLANGE SCREW 1/4-20 X 3/8 57 P0815057 CHAIN 06B X 59
4 P0815004 FLANGE SCREW #10-24 X 3/8 58 P0815058 BALL BEARING 6205-2RS
5 P0815005 BELT HOUSING LOWER COVER 59 P0815059 CHIP BREAKER
6 P0815006 CAP SCREW M8-1.25 X 25 60 P0815060 CHIP BREAKER ADJUSTMENT ROD
7 P0815007 DUST PORT 4" 61 P0815061 FLAT WASHER 10MM
8 P0815008 HEX BOLT 3/8-16 X 1-3/4 62 P0815062 E-CLIP 15MM
9 P0815009 FLANGE SCREW 1/4-20 X 5/16 63 P0815063 SPACER
10 P0815010 MOTOR PLATE 64 P0815064 ANTI-KICKBACK FINGER
11 P0815011 CAP SCREW M8-1.25 X 20 65 P0815065 ANTI-KICKBACK SHAFT
12 P0815012 CAP SCREW 3/8-16 X 1-1/4 66 P0815066 INFEED ROLLER
13 P0815013 FLAT WASHER 3/8 67 P0815067 SPROCKET 27T
14 P0815014 BUSHING 69 P0815069 BALL BEARING 6204-2RS
15 P0815015 PLATE 70 P0815070 CUTTERHEAD DRIVE GEAR 14T
16 P0815016 CAP SCREW M10-1.25 X 20 71 P0815071 CAP SCREW M6-1 X 25
17 P0815017 BALL BEARING 6000-2RS 72 P0815072 CAP SCREW 1/4-20 X 1-1/4
18 P0815018 LOCK WASHER 10MM 73 P0815073 GEAR 46T
19 P0815019 FLANGE SCREW 1/4-20 X 3/8 74 P0815074 GEARED SHAFT 18T
20 P0815020 ROLL PIN 5 X 15 75 P0815075 KEY 5 X 5 X 10
21 P0815021 HEX NUT 3/8-16 76 P0815076 GEARBOX COVER
22 P0815022 FLAT WASHER 1/4 77 P0815077 GEARBOX COVER PIN
23 P0815023 HANDWHEEL TYPE-3 8.5 D X 3/8B-K X 3/8-16 78 P0815078 BALL BEARING 6201-2RS
24 P0815024 REVOLVING HANDLE 3/8-16 X 5/8, 1 X 4 79 P0815079 COMBO GEAR 14T/22T
25 P0815025 HEADSTOCK COVER 80 P0815080 KEY 5 X 5 X 40
26 P0815026 CHIP DEFLECTOR 81 P0815081 GEAR 72T
27 P0815027 COLUMN CAP 82 P0815082 ROUND KNOB 3/8-16, 1-1/4 DIA
28 P0815028 CAP SCREW 3/8-16 X 2-1/2 83 P0815083 CHAIN 06B X 55
29 P0815029 ADJUSTABLE HANDLE M12-1.75, 125L 84 P0815084 SPROCKET 15T
30 P0815030 COLUMN GIB 85 P0815085 OIL PLUG 5/8 NPT (PLASTIC)
31 P0815031 COMPRESSION SPRING 3 X 12.7 X 40 86 P0815086 OIL SEAL 20 X 35 X 8
32 P0815032 HEAD CASTING 87 P0815087 GEARBOX
33 P0815033 PLATE SPRING 88 P0815088 GEARBOX GASKET
34 P0815034 OIL PORT M22-1.5 X 20 89 P0815089 COMBO GEAR 71T/79T
35 P0815035 SET SCREW 1/4-20 X 5/8 90 P0815090 GEAR SHAFT
36 P0815036 KEY 8 X 8 X 36 91 P0815091 COMPRESSION SPRING 0.5 X 4.8 X 18
37 P0815037 COLUMN LOCK ROD 92 P0815092 STEEL BALL 5MM
38 P0815038 COLUMN GIB (THREADED) 93 P0815093 INT RETAINING RING 47MM
39 P0815039 SWITCH MOUNT BRACKET 94 P0815094 BALL BEARING 6204-2RS
40 P0815040 DRIVE CHAIN COVER 95 P0815095 SHIFTER FORK
41 P0815041 MAG SWITCH ASSY SDE MP-15 240V 3HP 96 P0815096 FEED RATE SHIFTER SHAFT
41-1 P0815041-1 MAG SWITCH BOX 97 P0815097 O-RING 12MM
41-2 P0815041-2 CONTACTOR SDE MA-15 220V 98 P0815098 KEY 5 X 5 X 30
41-3 P0815041-3 OL RELAY SDE RA-20 12-18A 99 P0815099 CHAIN COVER PLATE
42 P0815042 SET SCREW 5/16-18 X 1/2 100 P0815100 CAP SCREW 5/16-18 X 1
43 P0815043 CAP SCREW 1/4-20 X 5/8
