Grizzly G0886 User Manual

Model G0886 (Mfd. Since 01/19)
-29-
9. Loosen blade tension handwheel (see
Figure 30), and remove blade from wheels.
Figure 31. Installing new blade.
Note: It is sometimes possible to flip the
blade inside out, in which case the blade
will be installed in the wrong direction. After
installing, check to make sure the blade
teeth face the same direction as blade travel
(see Figure 32). Some blades will have a
directional arrow as a guide.
Figure 32. Example of blade cutting direction.
Blade Travel
11. Apply a light amount of tension to hold blade
in place. Work your way around blade to
adjust position so back of blade is against
shoulder of wheels, as shown in Figure 33.
12. Perform Tensioning Blade procedure that
follows this section.
13. Re-install blade brush and blade guards, then
close wheel covers. Ensure guards do not
touch blade.
Figure 33. Blade installed on wheels.
10. With help of an assistant, insert new blade
through both blade guides and bearings (see
Figure 31, then position it around wheels.
Figure 30. Location of blade tension handwheel.
Bearings
Bearings
Blade
Idler Wheel
Wheel
Shoulder
Blade
Blade
Tension
Handwheel
Blade
Guides
