Grizzly G0938 - Stand Components and Labels Lists

-42-
Model G0938 (Mfd. Since 03/21)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
119
120
125
123
127
131
129
121
121
122
133
128
132
126
124
130
Stand
REF PART # DESCRI PTI ON REF PART # DESCRI PTI ON
119 P0938119 FLAT WASHER 8MM 127 P0938127 SUPPORT BRACKET, LOWER (REAR)
120 P0938120 HEX BOLT M8-1.25 X 45 128 P0938128 SUPPORT BRACKET, LOWER (SIDE)
121 P0938121 FLANGE NUT M8-1.25 129 P0938129 SUPPORT BRACKET, UPPER (REAR)
122 P0938122 CARRIAGE BOLT M8-1.25 X 12 130 P0938130 LEG, FRONT
123 P0938123 SPACER 9 X 14 X 20 131 P0938131 LEG, REAR
124 P0938124 FOOT, FRONT 132 P0938132 FOOT, REAR
125 P0938125 SUPPORT BRACKET, UPPER (SIDE) 133 P0938133 SUPPORT BRACKET, UPPER (FRONT)
126 P0938126 SUPPORT BRACKET, LOWER (FRONT)
