Grizzly G1066R User Manual

-58-
Model G1066R/Z/G1079R (Mfd. Since 02/11)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1066R Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1066R001 FRAME 48 P1066R048 FLAT WASHER 1/4
2 P1066R002 HEX NUT 3/8-16 49 P1066R049 HEX BOLT 5/16-18 X 1
3 P1066R003 FLAT WASHER 3/8 50 P1066R050 GUARD HINGED LEFT
4 P1066R004 SIDE PANEL 51 P1066R051 ROLLER BRACKET
5 P1066R005 BUSHING 51V2 P1066R051V2 ROLLER BRACKET V2.02.11
6 P1066R006 SPROCKET 53 P1066R053 FLAT HD SCR 1/4-20 X 2-3/8
7 P1066R007 SPROCKET 54 P1066R054 IDLE ROLLER SMOOTH 24 IN
7-1 P1066R007-1 SHAFT 55 P1066R055 BRACKET
8 P1066R008 TABLE SCREW FINE THREADS 3/4-16 58 P1066R058 CAP SCREW 1/4-20 X 3/4
8-1 P1066R008-1 TABLE SCREW SHIM 1/2 X 27 X 1 59 P1066R059 GUARD RIGHT
9 P1066R009 CHAIN 60 P1066R060 ROLLER BRACKET BOLT 1/2-13 X 70
10 P1066R010 FRONT BRACE 61 P1066R061 BUSHING SUPPORT
11 P1066R011 SET SCREW 5/16-24 X 3/8 62 P1066R062 BUSHING
12 P1066R012 COMPLETE CRANK HANDLE ASSY 64 P1066R064 PLATE
13 P1066R013 DUST HOOD 65 P1066R065 DRIVE ROLLER KNURLED 24 IN
14 P1066R014 HOOD 66 P1066R066 TABLE 12 HOLE
15 P1066R015 REAR BRACE 67 P1066R067 SET SCREW 1/4-20 X 1/2
16 P1066R016 REAR PANEL 68 P1066R068 SPROCKET 24T
17 P1066R017 SET SCREW 1/4-20 X 1/2 69 P1066R069 RUBBER CONVEYOR BELT
18 P1066R018 MOTOR PULLEY 70 P1066R070 PRESSURE ROLLER
19 P1066R019 KEY 1/4 X 1/4 X 3 71 P1066R071 SANDING DRUM
20 P1066R020 DRUM MOTOR 5HP 220V 1-PH 73 P1066R073 EXT RETAINING RING 19MM
20-1 P1066R020-1 MOTOR FAN 76 P1066R076 CLIP
20-2 P1066R020-2 MOTOR FAN COVER 77 P1066R077 TENSION WHEEL
20-3 P1066R020-3 S CAPACITOR 600M 125V 1-3/4 X 3-3/8 78 P1066R078 FLAT HD ALLEN SCR 1/4-20 X 1/2
20-4 P1066R020-4 R CAPACITOR 50M 350V 1-3/4 X 3-3/8 79 P1066R079 PILLOW BLOCK BEARING UCP205
20-5 P1066R020-5 CAPACITOR COVER 81 P1066R081 BEARING BLOCK
20-6 P1066R020-6 JUNCTION BOX 82 P1066R082 BEARING BLOCK PLATE, TAPPED
20-7 P1066R020-7 CENTRIFUGAL SWITCH 83 P1066R083 GREASE FITTING M6-1 X 5
22 P1066R022 HEX BOLT 3/8-16 X 1 85 P1066R085 FLAT WASHER 3/8
23 P1066R023 BRACKET 86 P1066R086 LOCK NUT 3/8-16
24 P1066R024 FLAT WASHER 3/8 87 P1066R087 TENSION SPRING
29 P1066R029 TAP SCREW #6 X 1/2 88 P1066R088 COMPRESSION SPRING
30 P1066R030 GROMMET 35 X 26MM 89 P1066R089 HEX BOLT M6-1 X 8
31 P1066R031 POWER CORD 12G 3W 86" 90 P1066R090 FLAT WASHER 3/8
32 P1066R032 FRONT PANEL 91 P1066R091 HEX BOLT M8-1.25 X 24
33 P1066R033 5 HP MAGNETIC SWITCH SINGLE-PHASE 92 P1066R092 SANDING ROLL 6" x 50' A60-X CLOTH
34 P1066R034 HEX NUT 5/16-18 93 P1066R093 SET SCREW 1/4-20 X 1/2
35V2 P1066R035V2 HEX NUT 3/4-16 1-1/4" DIA V2.08.02 94 P1066R094 DRUM PULLEY
36 P1066R036 TABLE FRAME 95 P1066R095 KEY 6 X 6 X 30
37 P1066R037 FLAT WASHER 5/16 97 P1066R097 SET SCREW M6-1 X 8
38 P1066R038 LOCK NUT 1/4-20 98 P1066R098 V-BELT B67
39 P1066R039 FEED MOTOR 1/4HP 220V 1-PH 99 P1066R099 FELT 19 X 24 IN
39-1 P1066R039-1 MOTOR FAN 101 P1066R101 STRIKE
39-2 P1066R039-2 MOTOR FAN COVER 102 P1066R102 LATCH
39-3 P1066R039-3 R CAPACITOR 12M 350V 1-3/8 X 2 105 P1066R105 SET SCREW 5/16-24 X 5/8
39-4 P1066R039-4 JUNCTION BOX 106 P1066R106 HEX NUT 1/4-20
40 P1066R040 FLAT WASHER 5/16 107 P1066R107 HEX BOLT 1/4-20 X 1/2
41 P1066R041 HEX NUT 5/16-18 109 P1066R109 PHLP HD SCR 10-24 X 5/8
42 P1066R042 KEY 5 X 5 X 20 115 P1066R115 SPRING PLATE
43 P1066R043 CHAIN 116 P1066R116 DUST SCOOP DEFLECTOR
44 P1066R044 SPROCKET 117 P1066R117 MOTOR CORD 12G 3W 36"
45 P1066R045 SET SCREW 1/4-20 X 1/4 124 P1066R124 HEX NUT 10-24
46 P1066R046 MOTOR BRACKET 125 P1066R125 FLAT WASHER 1/4
47 P1066R047 CAP SCREW 3/8-16 X 3/4 137 P1066R137 PHLP HD SCR 10-24 X 3/8
