Grizzly G1066R User Manual

Model G1066R/Z/G1079R (Mfd. Since 02/11)
-63-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1066Z Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1066Z001 FRAME 45 P1066Z045 SET SCREW 1/4-20 X 1/4
2 P1066Z002 HEX NUT 3/8-16 46 P1066Z046 MOTOR BRACKET
3 P1066Z003 FLAT WASHER 3/8 47 P1066Z047 CAP SCREW 1/4-20 X 3/4
4 P1066Z004 SIDE PANEL 48 P1066Z048 FLAT WASHER 1/4
5 P1066Z005 FLAT WASHER 1/2 49 P1066Z049 HEX BOLT 5/16-18 X 1-1/4
6 P1066Z006 SPROCKET 50 P1066Z050 GUARD HINGED LEFT
7 P1066Z007 SPROCKET 51 P1066Z051 ROLLER BRACKET
7-1 P1066Z007-1 SHAFT 52 P1066Z052 FLAT HD SCR 1/4-20 X 1
8 P1066Z008 TABLE SCREW FINE THREADS 3/4-16 53 P1066Z053 POWER CORD 12G 3W 36"
8-1 P1066Z008-1 TABLE SCREW SHIM 1/2 X 27 X 1 54 P1066Z054 POWER CORD 12G 3W 36"
9 P1066Z009 CHAIN 55 P1066Z055 LOCK NUT 1/4-20
10 P1066Z010 FRONT BRACE 56 P1066Z056 LOCK NUT M4-.7
11 P1066Z011 SET SCREW 5/16-24 X 3/8 58 P1066Z058 CAP SCREW 1/4-20 X 3/4
12 P1066Z012 COMPLETE CRANK HANDLE ASSY 59 P1066Z059 GUARD RIGHT
13 P1066Z013 DUST HOOD 60 P1066Z060 ROLLER BRACKET BOLT 1/2-13 X 70
14 P1066Z014 HOOD 61 P1066Z061 BUSHING SUPPORT
15 P1066Z015 REAR BRACE 62 P1066Z062 HEX BOLT 1/4-20 X 1/4
16 P1066Z016 REAR PANEL 63 P1066Z063 FLAT WASHER 1/4
17 P1066Z017 SET SCREW 1/4-20 X 1/2 64 P1066Z064 PLATE
18 P1066Z018 MOTOR PULLEY 65 P1066Z065 DRIVE ROLLER KNURLED 24 IN
19 P1066Z019 KEY 5 X 5 X 25 66 P1066Z066 TABLE 12 HOLE
20 P1066Z020 DRUM MOTOR 5HP 220V 1-PH 67 P1066Z067 SET SCREW 5/16-18 X 1/2
20-1 P1066Z020-1 MOTOR FAN 68 P1066Z068 SPROCKET
20-2 P1066Z020-2 MOTOR FAN COVER 69 P1066Z069 RUBBER CONVEYOR BELT
20-3 P1066Z020-3 S CAPACITOR 600M 125V 1-3/4 X 3-3/8 70 P1066Z070 PRESSURE ROLLER
20-4 P1066Z020-4 R CAPACITOR 50M 350V 1-3/4 X 3-3/8 71 P1066Z071 SANDING DRUM
20-5 P1066Z020-5 CAPACITOR COVER 72 P1066Z072 IDLE ROLLER SMOOTH 24 IN
20-6 P1066Z020-6 JUNCTION BOX 73 P1066Z073 EXT RETAINING RING 19MM
20-7 P1066Z020-7 CENTRIFUGAL SWITCH 74 P1066Z074 BUSHING
21 P1066Z021 HEX NUT 3/8-16 75 P1066Z075 BRACKET
22 P1066Z022 HEX BOLT 3/8-16 X 1 77 P1066Z077 FLAT WASHER 1/4
23 P1066Z023 BRACKET 78 P1066Z078 TAP SCREW 1/4 X 1-1/2
24 P1066Z024 FLAT WASHER 3/8 79 P1066Z079 SIDE PANEL
25 P1066Z025 PHLP HD SCR M4-.7 X 10 80 P1066Z080 DUST HOOD
26 P1066Z026 FLAT WASHER 3/8 81 P1066Z081 BEARING BLOCK SET
27 P1066Z027 HEX NUT 3/8-16 82 P1066Z082 SET SCREW 5/16-24 X 1/2
28 P1066Z028 DUST DEFLECTOR 84 P1066Z084 BEARING BLOCK PLATE, TAPPED
29 P1066Z029 TAP SCREW #8 X 3/8 85 P1066Z085 FLAT WASHER 3/8
30 P1066Z030 GROMMET 29 X 25MM 86 P1066Z086 LOCK NUT 3/8-16
31 P1066Z031 POWER CORD 12G 3W 86" 88 P1066Z088 COMPRESSION SPRING
32 P1066Z032 FRONT PANEL 89 P1066Z089 HEX BOLT 1/4-20 X 3/8
33V2 P1066Z033V2 CONTACTOR SDE MA-30 240V V2.05.16 90 P1066Z090 FLAT WASHER 3/8
34 P1066Z034 HEX NUT 5/16-18 91 P1066Z091 HEX BOLT M8-1.25 X 24
35 P1066Z035 HEX NUT 3/4-16 1-1/4" DIA 92 P1066Z092 SANDING ROLL 3" x 50' A60 H&L
36 P1066Z036 TABLE FRAME 93 P1066Z093 SET SCREW 3/8-16 X 1/2
37 P1066Z037 FLAT WASHER 5/16 94 P1066Z094 DRUM PULLEY
38 P1066Z038 SET SCREW 3/8-16 X 1/4 95 P1066Z095 KEY 1/4 X 1/4 X 1-1/4
39 P1066Z039 FEED BELT MOTOR 1/3HP 60V 1-PH 96 P1066Z096 SANDING ROLL 3" x 50' A100 H&L
40 P1066Z040 FLAT WASHER 5/16 97 P1066Z097 SET SCREW M6-1 X 6
41 P1066Z041 HEX NUT 5/16-18 98 P1066Z098 V-BELT B67
42 P1066Z042 KEY 5 X 5 X 20 101 P1066Z101 STRIKE
43 P1066Z043 CHAIN 102 P1066Z102 LATCH
44 P1066Z044 SPROCKET 105 P1066Z105 SPRING PLATE
