Model G1066R/Z/G1079R (Mfd. Since 02/11)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G1079R Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P1079R001 FRAME 47 P1079R047 CAP SCREW 1/4-20 X 3/4
2 P1079R002 HEX NUT 3/8-16 48 P1079R048 FLAT WASHER 1/4
3 P1079R003 FLAT WASHER 3/8 49 P1079R049 HEX BOLT 5/16-18 X 1
4 P1079R004 SIDE PANEL 50 P1079R050 GUARD HINGED LEFT
5 P1079R005 BUSHING 51V2 P1079R051V2 ROLLER BRACKET V2.02.11
6 P1079R006 SPROCKET 53 P1079R053 FLAT HD SCR 1/4-20 X 2-3/8
7 P1079R007 SPROCKET 55 P1079R055 LATCH
7-1 P1079R007-1 SHAFT 56 P1079R056 LOCK WASHER 1/4
8 P1079R008 TABLE SCREW 3/4-16 58 P1079R058 CAP SCREW 1/4-20 X 3/4
8-1 P1079R008-1 TABLE SCREW SHIM 1/2 X 27 X 1 59 P1079R059 ROLLER GUARD
8-2 P1079R008-2 TABLE SCREW SHIM 1/2 X 28 X 3 60 P1079R060 ROLLER AJUST BOLT 1/2-13 X 70
9 P1079R009 ELEVATION CHAIN 61 P1079R061 BUSHING SUPPORT
10 P1079R010 FRONT BRACE 63 P1079R063 IDLER ROLLER
11 P1079R011 SET SCREW 1/4-20 X 1/2 64 P1079R064 PLATE
12 P1079R012 COMPLETE CRANK HANDLE ASSY 65 P1079R065 DRIVE ROLLER
13 P1079R013 DUST PORT 66 P1079R066 TABLE
14V2 P1079R014V2 HOOD V2.02.11 67 P1079R067 SET SCREW 1/4-20 X 1/2
15V2 P1079R015V2 REAR BRACE V2.02.11 68 P1079R068 SPROCKET
16V2 P1079R016V2 REAR PANEL V2.02.11 69 P1079R069 RUBBER CONVEYOR BELT
17 P1079R017 SET SCREW 5/16-18 X 1/2 70 P1079R070 PRESSURE ROLLER
18 P1079R018 MOTOR PULLEY 71 P1079R071 SANDING DRUM
19 P1079R019 KEY 1/4 X 1/4 X 3 73 P1079R073 EXT RETAINING RING 19MM
20 P1079R020 DRUM MOTOR 2HP, 220V, 1-PH 74 P1079R074 BUSHING
20-1 P1079R020-1 DRUM MOTOR FAN COVER 76 P1079R076 CLIP
20-2 P1079R020-2 DRUM MOTOR FAN 77 P1079R077 TENSION WHEEL
20-3 P1079R020-3 S CAPACITOR 400M 125V 1-3/4 X 3-3/8 78 P1079R078 FLAT HD ALLEN SCR 1/4-20 X 1/2
20-4 P1079R020-4 DRUM MOTOR JUNCTION BOX 79 P1079R079 PILLOW BLOCK BEARING UCP205
20-5 P1079R020-5 CENTRIFUGAL SWITCH 81 P1079R081 BEARING BLOCK
21 P1079R021 HEX NUT 3/8-16 82 P1079R082 SET SCREW 5/16-24 X 1/2
22 P1079R022 HEX BOLT 3/8-16 X 3/4 83 P1079R083 GREASE FITTING M6-1 X 5
23 P1079R023 HEX BOLT 1/4-20 X 3/4 84 P1079R084 FLAT WASHER 1/4
24 P1079R024 FLAT WASHER 3/8 85 P1079R085 FLAT WASHER 3/8
25 P1079R025 HEX NUT 1/4-20 86 P1079R086 LOCK NUT 3/8-16
26 P1079R026 SPRING PLATE 87 P1079R087 TENSION SPRING
27 P1079R027 ADJUST PLATE 88 P1079R088 COMPRESSION SPRING
29 P1079R029 TAP SCREW #6 X 1/2 89 P1079R089 HEX BOLT1/4-20 X 3/8
31V2 P1079R031V2 POWER CORD 14G 3W 7' V2.02.09 90 P1079R090 BRACKET
32V2 P1079R032V2 FRONT PANEL V2.02.11 91 P1079R091 SANDING ROLL 6" x 50' A60-X CLOTH
33V2 P1079R033V2 SINGLE PHASE ON/OFF SWITCH V2.02.11 92 P1079R092 SANDING ROLL 6" x 50' A100-X CLOTH
34 P1079R034 HEX NUT 5/16-18 93 P1079R093 KEY 6 X 6 X 30
35 P1079R035 HEX NUT 3/4-16 94 P1079R094 SANDING DRUM PULLEY
36 P1079R036 TABLE FRAME 97 P1079R097 SET SCREW 3/8-16 X 1/2
38 P1079R038 LOCK NUT 1/4-20 98 P1079R098 V-BELT B60
39 P1079R039 FEED MOTOR 1/4HP 99 P1079R099 FELT 19 X 24 IN
39-1 P1079R039-1 R CAPACITOR 12M 350V 1-1/2 X 2 100 P1079R100 SWITCH BOX
39-2 P1079R039-2 FEED MOTOR FAN COVER 101 P1079R101 STRIKE
39-3 P1079R039-3 FEED MOTOR FAN 104 P1079R104 CONTROL WIRE 1015 16G 130MM
39-4 P1079R039-4 FEED MOTOR JUNCTION BOX 105 P1079R105 OVERLOAD BUTTON MB-15A
40 P1079R040 FLAT WASHER 5/16 108 P1079R108 SET SCREW 1/4-20 X 1/2
41 P1079R041 HEX NUT 5/16-18 116 P1079R116 DUST SCOOP DEFLECTOR
42 P1079R042 KEY 5 X 5 X 20 117V2 P1079R117V2 MOTOR CORD 16G 3W 30" V2.02.11
43 P1079R043 DRIVE CHAIN 118V2 P1079R118V2 FEED MOTOR CORD V2.02.09
44 P1079R044 SPROCKET 137 P1079R137 FLANGE BOLT 10-24 X 3/8
45 P1079R045 SET SCREW 1/4-20 X 1/4 139 P1079R139 TAP SCREW #8 X 1/2
46 P1079R046 MOTOR BRACKET 140 P1079R140 FLAT WASHER #10
149 P1079R149 HEX WRENCH 3MM
