Description Qty
A. Headstock .................................................. 1
B. Base ........................................................... 1
C. Chuck Guard Assembly ............................. 1
D. Wrench ...................................................... 1
E. Hex Bolt and Wingnut Set .......................... 1
F. Column ....................................................... 1
G. Key ............................................................. 1
H. Chuck ......................................................... 3
I. Lock Levers ...................................... 2 Small
J. Crank Arm and Handle ........................1 Ea
K. Downfeed Handles ..................................... 3
Inventory
If any nonproprietary parts are missing (e.g. a nut or a washer), we would be glad to replace them, but for
the sake of expediency, you can get replacements at a hardware store.
Use Figure 5 and the inventory list below to inventory your drill press parts:
L. Table ........................................................... 1
M. Lock Shoe (Headstock) .............................. 1
N. Table Support Arm (G7946) ...................... 1
O. Column Support Arm (G7946) .................... 1
P. Hardware Bag (Not Shown) ........................ 1
—Hex Bolts M8-1.25 x 20 (G7945) ............ 4
—Hex Bolts M10-1.5 x 40 (G7946) ............. 4
—Hex Wrench 3mm ................................... 1
—Hex Wrench 4mm ................................... 1
—Phillips Head Screws M4-.7 x 10 ............ 4
—Flat Washers 4mm .................................. 8
Figure 5. Parts inventory for Models G7945 (top) and G7946 (bottom).
L K
F
E
DC
J
I H G
A B
K
J
L
EDC
I H G
F
A B
M
M
NO
G7945
G7946
