Grizzly G7945 - Identification of Controls and Features; Right-Side Controls; Left-Side Controls

Model G7945/G7946 (Mfd. Since 09/17)
-3-
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
A. Power Switch
B. Headstock
C. Downfeed Handles
D. Horizontal Adjustment Knob
E. Lock Levers
F. Belt Tension Lock Knobs
G. Crank Handle
H. Lock Pin
I. Headstock Angle Tilt Scale
J. Spindle Return Spring
K. Depth Stop
L. Spindle
E
A
B
C
D
K
G
I
L
Right-Side Controls Left-Side Controls
F
E
H
J
