Grizzly G7945 - Labels and Cosmetics

-46-
Model G7945/G7946 (Mfd. Since 09/17)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G7945/G7946 Labels & Cosmetics
REF PART # DESCRIPTION REF PART # DESCRIPTION
93 P7945093 LABEL (TIPPING WARNING) 133 P7945133 SHOCK-PINCH WARNING LABEL
102V2 P7945102V2 MACHINE ID LABEL V2.04.18 (G7945) 134 P7945134 READ-ENTANGLE-EYE LABEL
102V2 P7946102V2 MACHINE ID LABEL V2.04.18 (G7946) 135 P7945135 TOUCH-UP PAINT, GRIZZLY GREEN
116 P7945116 ELECTRICITY WARNING LABEL 136 P7945136 TOUCH-UP PAINT, GLOSSY BLACK
Specifications
WARNING!
7. Clamp workpiece to table to prevent rotation.
8. Avoid putting hands where they could slip into rotating
bits.
9. Always remove chuck keys and other tools before starting.
10. Use correct speeds for drilling accessories and workpiece.
11. Do not expose to rain or use in wet locations.
12. Prevent unauthorized use by children or untrained users.
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses.
3. Only plug power cord into a grounded outlet.
4. Disconnect power before setting up or servicing.
5. Tie back long hair, roll up long sleeves, and DO NOT
wear loose clothing, gloves, or jewelry.
6. Keep all guards and covers in place during operation.
Motor: 1/2 HP, 120V, 4.7A, 60 Hz
Swing: 11"– 34"
Spindle Speeds: 550 – 3000 RPM
Spindle to Table Dist.: 30-1/2"
Spindle to Base Dist.: 51"
Spindle Travel: 3-1/4"
Spindle Taper: JT#33
Weight: 138 Lbs.
To reduce the risk of serious injury when using this machine:
MODEL G7946
FLOOR RADIAL
DRILL PRESS
Manufactured for Grizzly in China
Date
Serial #
184841
93
102V2
116
133
134
135
136
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
Always keep this
cover closed
during operation.
PINCH
HAZARD!
WARNING!
WARNING!
ENTANGLEMENT
HAZARD!
Tie back long hair, roll up
long sleeves, and remove
loose clothing, jewelry, or
gloves to prevent getting
caught in moving parts.
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
WARNING!
Always wear
ANSI-approved safety
glasses and face
shield when using
this machine.
EYE/FACE INJURY
HAZARD!
WARNING!
WARNING!
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
