Grizzly G7945 - Page 47

Model G7945/G7946 (Mfd. Since 09/17)
-45-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P7945001 BASE 72-1 P7945072-1 CRANK HANDLE
3 P7945003 HEX BOLT M8-1.25 X 20 73 P7945073 SET SCREW M6-1 X 10
4 P7945004 SHORT RACK 74 P7945074 10T GEAR
5 P7945005 SHORT VERTICAL COLUMN 78 P7945078 HEX BOLT M12-1.75 x 30
7 P7945007 GEARED TABLE BRACKET 80 P7945080 COLUMN RING
7-1 P7945007-1 TABLE BRACKET ASSEMBLY 83 P7945083 SQUARE TABLE
11 P7945011 LOCK LEVER M10-1.5 X 30 93-1 P7945093-1 HEX BOLT M8-1.25 X 125
13 P7945013 HORIZ BRACKET 2-5/16 V2.02.99 97 P7945097 WING NUT M8-1.25
70 P7945070 PIN 112 P7945112 LOCK WASHER 12MM
71 P7945071 WORM SHAFT 123 P7945123 SPECIAL WRENCH
72 P7945072 FIXED HANDLE M8-1.25 X 10, 21 X 76
G7945 Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P7946001 BASE V2.04.03 74 P7946074 WORM GEAR
3 P7946003 HEX BOLT M10-1.5 X 35 80 P7946080 COLUMN RING
4 P7946004 LONG COLUMN W/COLUMN HOLDER V3.02.99 83 P7946083 ROUND TABLE
4A-1 P7946004A-1 LONG RACK 84 P7946084 COLUMN SUPPORT ARM
7 P7946007 GEARED TABLE BRACKET V2.03.99 84A P7946084A TABLE SUPPORT ARM
7-1 P7946007-1 COMPLETE TBL BRKT ASSY 92 P7946092 LOCK LEVER M12-1.75 X 50
11 P7946011 LOCK LEVER M10-1.5 X 50 93-1 P7946093-1 HEX BOLT M8-1.25 X 125
13 P7946013 HORIZONTAL COLUMN BRACKET 96 P7946096 HEX BOLT 5/8-13 X 1-1/2
70 P7946070 AXLE 97 P7946097 WING NUT M8-1.25
71 P7946071 WORM PINION 123 P7946123 SPECIAL WRENCH
72 P7946072 FIXED HANDLE M8-1.25 X 10, 21 X 76 127 P7946127 HEX NUT M6-1
72-1 P7946072-1 CRANK HANDLE 128 P7946128 LOCATING PIN
73 P7946073 SET SCREW M6-1 X 10 129 P7946129 FLAT WASHER 16MM
G7946 Column Parts List
