7. Functional description
TheBEKAONEisanelectromechanicallubricatorforlubricatingasinglelubepoint.
ThedeviceisdesignedtoconveyoilorgreaseuptoNLGI2.
TheBEKAONElubricatorismadeforanindependentoperation.Powerissuppliedbyexchangeable
batteries.
Thelubricantisoptionallycontainedinareservoirwithfollowerplateorinacartridge.Therellable
followerplatereservoirhasallingvolumeof120ml.Thecartridgewithallingvolumeof120mlis
intendedforsingleuseandcanbeeasilyreplaced.
Dependingontheusedlubricantorthetypeofbattery,andtheenvironmentalconditionsthefollow-
uppistonreservoirorthecartridgecanbeemptiedbetween1and5timeswithonesetofbatteries.
Fig.1:
Thedeviceisapistonpump,i.e.0.24mllubricantarecontinuouslyconveyedperpistonstroke.
Settingofthelubricantquantityisdoneonamonthlybasis(seechapter9.6Setthemonthsetting).
Month setting Lubricant qty per month (cm³) Lubricant qty per week (cm³)
24 5 1.1
12 10 2.3
6 20 4.6
3 40 9.2
1 120 27.5
ThemonthsettingisdoneattheactivationareawiththeActivationmagnet(g.1)orwiththe
Settingsbutton(g.1)(seechapter9.6Setthemonthsetting).
The current functional state of the device is displayed at the LED bar (see chapter 11.4).
Activation magnet
Protective housing
Settings
button
Battery
compartment
LED bar
Activation
zone
