9.1.3 Relling the follower plate reservoir
• Cleanthedevicerst,especiallythellingttinganditsimmediatesurroundingsinordertoprevent
contamination.
• Fillthereservoiruntiltheredpistonisatallevelwiththeupperedge.
Neverllthedeviceabovemax.leveltopreventpossibledamage.
• Observethelubricantspecicationsofthemachinemanufacturer!
Onlyuselubricantsacc.tothespecicationsofthemachinemanufacturer!
• Collectanyoutcominglubricantinasuitablereceptacleanddisposeofitprofessionally!
• Observe the safety data sheet of the lubricant manufacturer.
• Pleasemindthatthelubricantviscositychangeswiththeoperatingtemperature!
• Payattentiontoutmostcleanlinesswhenlling!
Fig.5:
• Actuateintermediatelubricationprocessesaftereachllinguntilthelubriantescapesatthedevice
outlet free of air inclusions.
• Proceed as described under 11.5 Actuate an intermediate lubrication.
• Cleanthellingtting.
• Placethetransparentprotectivehousingonthedeviceagainandtightenit.
Becarefulnottoovertightenthecover!
Attention!
Note!
Filling
fitting
Fill until the red
piston is flush
Red piston
Attention!
