9. Commissioning
9.1 Filling the devices
9.1.1 Initial lling when using a reservoir with follow-up piston
You have to ll the ducts of the device with lubricant before you install the
follow-up piston reservoir.
• Detachtheprotectivehousingbyturningitcounter-clockwise.
Useahand-operatedgreasegunforlling.
• Cleanthedevicerst,especiallythellingttinganditsimmediatesurroundingsinordertoprevent
contamination.
• Placethehoseofthegreasegunonthellingtting(g.3left)andpressthelubricantintothe
deviceuntilitgetsvisibleintheintakearea(g.3right).
Fig.3:
• Continue installation of the follower plate reservoir (see chapter 9.1.2 Installation of the follower
plate reservoir).
Attention!
Note!
Filling fitting
Lubricant
