11.5 Actuate an intermediate lubrication
Youcanactuateanintermediatelubricationforafunctionalcheckofyourdevice.
PayattentionthattheBEKAONEisswitchedonandcorrectlysetbeforethe
intermediate lubrication process (see chapter 9.5 Switch on the device).
• Takeo󰀨theactivationmagnetfromthetopandapproachtheactivationzone(g.18).
• PlacetheactivationmagnetontheactivationzoneandholditthereuntiltheredLEDhasashed
2x(g.18).Thenremovetheactivationmagnet.
• OryoucanalsopressthesettingsbuttonandreleaseitwhentheredLEDhasashed2x.
• ThegreenLEDlightsupaccordingtotheselectedmonthsetting.
• The pump will start the intermediate lubrication cycle (ca. 20 s):
Fig.18:
11.6 Switch o󰀨 the device
• Placetheactivationmagnetontheactivationzone(g.19)andholditthereuntiltheredandthe
orangeLEDhaveashedalternately10x.Asanalternativeyoucanalsokeepthesettingsbutton
pressed.
• FlashingofallLEDssignalstoyoutoreleasethebuttonorremovetheactivationmagnet.
Fig.19:
• Thedeviceswitcheso󰀨.TheredLEDwilllightupfor3seconds.
Toswitchthedeviceonagain,proceedasdescribedunder9.5Switchonthedevice.
Note!
LED
flashes
Month setting
Activation zone
Activation-
magnet
Settings button
LED
2x
Activation zone
Activation
magnet
Settings button
LED
10x
Activation zone
Activation
magnet
Settings button
LED
3 sec
Note!
