Afterthelubricationprocessisthecurrentbackpressuredeterminedanddisplayedfor2s(seetable).
Fig.12:
(example:
orangeLEDlightsup=
increasedbackpressure)
10. Assembly instructions
Checkthedeviceforpossibletransportdamageandforcompletenessbeforeassembly.
Removeanyattacheddevicesfortransportationsafety.
Thefollowingconditionsmustbefullledwhenyouassemblethedevicesothatitcan
be properly mounted and form with other parts a complete machine in environmentally
friendlymannerandwithoutcompromisingthesafetyandhealthofpersons.
Mountthedeviceinbalanceonbothsidesandwiththereservoiruprighttoensuresafeoperation.
Thedevicemustnotbeexposedtocentrifugalforces.
10.1 General installation instructions
Selecttheinstallationlocationforthedevicesothatitisprotectedagainstenvironmentaland
mechanicalinuencesinthebestpossibleway.
Ensurefullaccess,forexampleforrellingoflubricantorvisualinspections.
LED Backpressure (bar)
1green <=4
1+2green <=8
1+2+3green <=10
1+2+3+4green <=19
1+2+3+4+5green <=21
1+2+3+4+5+6orange <=25=increasedbackpressure,increasedenergyconsumption
1+2+3+4+5+6 red
>25=backpressuretoohigh,currentconsumptiontoohigh,
load leads to mechanical overstress
and failure of the device
LEDs
