Growatt MOD 11KTL3-X Manual

13.3 System error
Error code
Description
Suggest
Error 200
AFCI Fault
1 .After shutdown,Check the panel terminal.
2.Restart inverter.
3.If error message still exists,contact manufacturer.
Error 201
Leaka ge c u r -
r en t too high.
1 .Restart inverter.
2.If error message still exists,contact manufacturer.
Error 202
The DC input volt-
age is exceeding
the maximum toler-
able value.
1 .Immediately disconnect the DC switch and check the volt-
age
2.If the fault code still exists after the normal voltage is re-
stored, contact manufacturer
Error 203
PV isolation Low
1.After shutdown, check whether the panel shell is reliably
grounded.
2.If error message still exists,contact manufacturer.
Error 300
AC V Outrange
1 .Check grid voltage.
2.If the error message still exists despite the grid voltage be-
ing within the tolerable range, contact manufacturer.
Error 301
AC ter mi n a l s re-
versed
1 .Check AC terminals
2.If error message still exists,contact manufacturer.
Error 302
No AC Connection
1 .After shutdown,Check AC wiring.
2.If error message still exists,contact manufacturer.
Error 303
NE abnormal
1 .Check PE,to ensure that the PE line contact good. 2.If error
message still exisits,contact Manufacturer.
Error 304
AC F Outrange
1 .Restart inverter.
2.If error message still exists,contact manufacturer.
Error 305
Over Load Fault
1.Check whether output load over range; If load too large,
please reduce load
2.If error message still exists, contact manufacturer.
Error 306
CT LN Reversed
1 .After shutdown Check the SP-CT connection.
2.If error message still exists,contact manufacturer.
Error 307
Co mm un i c at i o n
fault M3 didn't re-
ceive SP-CT data
1 .Check communication wire
2.If error message still exists,contact manufacturer.
Error 308
Co mm un i c at i o n
fault;Pairing time
too long
1 .Restart pairing
2.If error message still exists,contact manufacturer.
41

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
