Growatt MOD 11KTL3-X Manual

47
Model
Specifications
MOD
3000TL3-
X
MOD
4000TL3-
X
MOD
5000TL3-
X
MOD
6000TL3-
X
MOD
7000TL3-
X
MOD
8000TL3-
X
Protection devices
DC reverse-polarity pro-
tection
YES
DC switch
YES
DC Surge protection
typell OPT
Insulation resistance mon-
itoring
YES
AC surge protection
typell OPT
AC short-circuit protection
YES
Grid monitoring
YES
Anti-islanding protection
YES
Residual-current monitor-
ing unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W/ H / D) in
mm
425*387*147mm
425*387* 178mm
Weight
12.5kg
14kg
Operating temperature
range
-25°C ... +60°C (>45°CDerating)
Noise emission (typical)
<S35dB(A)
Altitude
4000m
Internal consumption at
night
1W
Topology
Transformerless
Cooling
Natural heat dissipation
Electronics protection de-
gree
IP66
Relative humidity
0-100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
