Growatt MOD 11KTL3-X Manual

Model
Specification s
MOD
9000TL3-X
MOD
10TL3-X
MOD
11TL3-X
MOD
12TL3-X
MOD
13TL3-X
MOD
15TL3-X
Input data(DC)
Max. recommended PV
power(for module STC)
13500W
15000W
16500W
18000W
19500W
22500W
Max. DC voltage
1100V
Start voltage
200V
Nominal voltage
580V
MPP voltage range
140-1 000V
No. of MPP trackers
2
No. of PV strings per MPP
trackers
1/1
1/1
1/1
1/2
1/2
1/2
Max. input current per
MPP trackers
13/13A
13/13A
13/13A
13/2 6 A
13/2 6 A
13/2 6 A
Max. short-circuit current
per MPP trackers
1 6/1 6A
1 6/1 6A
1 6/1 6A
16/32A
1 6/3 2 A
1 6/3 2 A
Backfeed current to PV array
Output data(AC)
AC nominal power
9000W
10000W
11 ooow
12000W
13000W
15000W
Max. AC apparent
9900VA
11000VA
12100VA
13200VA
14300VA
165000VA
Nominal AC voltage/range
230/400V
AC grid frequency/range
50/60 Hz
45~55Hz/55-65 Hz
Max. output current
15A
16.7A
18.3A
20.0A
21.7A
25A
AC inrush current
30A
Max. output fault current
44.5A
58.4A
Max. output overcurrent
Protection
44.5A
58.4A
Power factor(@nominal
power)
>0.99
Adjustable power factor
0.8Leading ...0.8Lagging
THDi
<3%
AC grid connection type
3W+PE /3W+N+PE
Efficiency
Max. efficiency
98.6%
Euro-eta
97%
48

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
