Growatt MOD 11KTL3-X Manual

Model
Specificatio ns
MOD MOD MOD 9000TL3-X
10KTL3-X 11KTL3-X
MOD MOD MOD 12KTL3-X
13KTL3-X 15KTL3-X
Protection devices
DC reverse-polarity pro-
tection
YES
DC switch
YES
DC Surge protection
typell OPT
Insulation resistance
monitoring
YES
AC surge protection
typell OPT
AC short-circuit protec-
tion
YES
Grid monitoring
YES
Anti-islanding protection
YES
Residual-current moni-
toring unit
YES
String Fuse protection
NO
String monitoring
OPT
AFCI protection
OPT
General data
Dimensions (W / H / D) in
mm
425*387* 178mm
Weight
14kg
16.0kg
Operating temperature
range
-25°C ... +60°C (>45°CDerating)
Noise emission (typical)
<35dB(A)
Altitude
4000m
Internal consumption at
night
1W
Topology
Transformerless
Cooling
Natural heat dissipation
Electronics protection de-
gree
IP66
Relative humidity
0-100%
DC connection
H4/MC4(OPT)
AC connection
Waterproof PG head+OT terminal or quick connect terminal
Interfaces
Display
OLED+LED
USB/RS485
YES
WIFI/GPRS/4G/RF/LAN
OPT
49

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
