Growatt SPH6000 User Manual

Chart 4.1
Item Number Description
A 1 SPH inverter
B 1 User Manual
C 1 Paper board(installation guide)
D 1 Waterproof cover
E 1 AC Grid connector
F 1 EPS output connector
G 1 Communication cable
H 1 Current sensor
I 1 Lead-acid battery temperature sensor
J 1 RJ45 connector
K 4 M6 setscrew
M 2 Battery power terminal
N 6 screw
O/P 2/2 MC4 connector
Q 1
Hex screwdriver
5 Installation
5.1 Basic installation requirements
A. The installation location must be suitable for SPH’s weight for a long period time
B. The installation location must conforms with dimension of SPH
C. Do not install the unit on structures constructed of flammable or thermo labile materials
D. The ingress Protection rate is IP65 and the pollution degree is PD2. Please refer to the below:

Growatt SPH6000 Specifications

General

Model	SPH6000
Category	Inverter
Rated Power	6000 W
Max. DC Voltage	550 V
Max. Output Current	27.3 A
Start Voltage	150 V
Nominal DC Voltage	360V
Number of DC Inputs	2
Number of MPP Trackers	2
Nominal AC Power	6000 W
Max. AC Power	6600 W
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Max. Output Power	6600 W
Output Voltage	230V
Output Frequency	50/60 Hz
Nominal AC Voltage	230V
AC Voltage Range	180V-280V
Power Factor	0.8 leading - 0.8 lagging
Communication	RS485
Cooling Method	Natural Convection
