33
English (US)
22.5 Other technical data
EMC (electromagnetic compatibility to EN 61800-3)
Contact Grundfos for further information.
Enclosure class
• Three-phase pumps, 1.5 - 10 hp: IP55 (IEC 34-5)
• Three-phase pumps, 15 - 30 hp: IP55 (IEC 34-5)
Insulation class
F (IEC 85)
Ambient temperature
During operation:
• Min -4 °F (-20 °C)
• Max +104 °F (40 °C) without derating
During storage/transport:
• -40 °F (-40 °C) to +140 °F (+60 °C) (1.5 - 10 hp)
• -13 °F (-25 °C) to +158 °F (70 °C) (15 - 30 hp)
Relative air humidity
Maximum 95 %.
Sound pressure level
Single-phase pumps:
< 70 dB(A).
Sound pressure level
23. Disposal
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company
or service workshop.
Subject to alterations.
Motor
[hp]
Emission/immunity
0.5
Emission:
The motors may be installed in residential areas
(first environment), unrestricted distribution,
corresponding to CISPR11, group 1, class B.
Immunity:
The motors fulfil the requirements for both the first
and second environment.
0.75
1
1.5
2
3
5
7.5
10
15
20
25
30
Emission:
The motors are category C3, corresponding to
CISPR11, group 2, class A, and may be installed in
industrial areas (second environment).
If equipped with an external Grundfos EMC filter, the
motors are category C2, corresponding to CISPR11,
group 1, class A, and may be installed in residential
areas (first environment).
Warning
When the motors are installed in
residential areas, supplementary
measures may be required as the
motors may cause radio interference.
Motor sizes 15, 25, and 30 hp comply with
EN 61000-3-12 provided that the short-circuit power
at the interface point between the user's electrical
installation and the public power supply network is
greater than or equal to the values stated below. It is
the responsibility of the installer or user to ensure, by
consultation with the power supply network operator,
if necessary, that the motor is connected to a power
supply with a short-circuit power greater than or
equal to these values:
Motor size
[hp]
Short-circuit power
[kVA]
15 1500
20 -
25 2700
30 3000
20 hp motors do not comply with
EN 61000-3-12.
By installing an appropriate harmonic filter between
the motor and the power supply, the harmonic
current content will be reduced. In this way, the
20 hp motor will comply with EN 61000-3-12.
Immunity:
The motors fulfill the requirements for both the first
and second environment.
Motor
[hp]
Speed stated on
the nameplate
Sound pressure
level
1.5
3400-3600
65
2.0 70
3.0 70
5.0 75
7.5 80
10 69
15 70
20 70
25 74
30 78
