Accessories
Hot injection valve
Hot injection valve
The hot injection valve kit is a complete assembly with
shut-off valve, pipe, and tubing connection fitting for
chemical injection into steam and hot water applica-
tions.
It allows for direct dosing into systems with a maximum
liquid temperature of 302 F (150 °C) at the point of
injection.
The hot injection valve kit is delivered non-assembled
to facilitate adaptation to the actual application.
Materials:
Shut-off ball valve 316 SS
Pipe 316 SS
Pipe connection 316 SS
Tubing connection PVDF
Max. injection point temperature 302 F (150 °C)
Dimensions:
Shut-off ball valve 1/2"
Pipe 8/10 mm
Pipe connection 1/2"
Tubing connection
3/8" ID 1/2" OD.
GR 7506
Max. flow rate GPH [l/h] Size
Material Connection
Product number
Connection Gasket Ball Type Tubing diameter
5.3 (20) DN 4 PVDF FKM Ceramic Tubing 3/8" / 1/2" 96567703
