Users can set the function switch to meet different applications. Before
setting the function switch, the controller should be disconnected from the
power supply.
After completing the setting, apply power to the controller and observe the
application sign displayed on the LCD conforming to the TRANSFER symbol.
Transfer Setting Transfer Symbol
DANGER Electric shock risk.
Before carrying out any installation or maintenance operation, the
controller should be disconnected from the power supply and one
should wait at least 2 minutes before opening the controller.
Never connect AC power to output L1&N1 / L2&N2 terminals.
Ensure the motor, controller and power specifications.
The electrical and hydraulic connections must be carried out by
competent, skilled, qualified personnel.
DIP
SWITCH
SETTINGS
