13. Display overviews
The following shows the display overviews for the PMU 2000, in-
cluding the basic menu and the display overviews for zone type
PFU and the control parameters “pressure” and “pressure with
pre-pressure measuring”.
The displays with double lines are only available on service code
level.
By pressing “Esc” repeatedly, you can always return to display
100.
111 Zone A 12
UPE 1 head
Zone A 12
UPE 2 head
Zone A 12
UPE 3 op.loop
Zone A 12
PFU 1 diffpr.
Zone A 12
PFU 2 tempdif
Zone A 12
PFU 3 temp.
Zone A 12
PFU 4 flow
Zone A 12
PFU 5 level
Zone A 12
PFU 6 op.loop.
Zone A 12
PFU 7 press.
Zone A 12
PFU 8 press.
Basic menu
100 1.2.3.4 5 6 7 8
Status I I 0 A M - -
101 Configuration 12345678
set to zone AAC
102 Configuration
presetting →
103 Configuration Mon
clock 11:07 h 21-07-94
104 Configuration
alarm suppression on
105 Configuration
pump comm. alarm on
106 Configuration PMU
GRUNDFOS 00620194/9420
107 Configuration PCU
GRUNDFOS 00610194/9420
108 Configuration PFU
GRUNDFOS 00630194/9420
Configuration
<<< End of menu >>>
