Appendix A
A.1. Minimum inlet pressure, 50 Hz, 2-pole
Pump type
(50 Hz)
p [bar]
20 °C 60 °C 90 °C 110 °C 120 °C 140 °C 150 °C
TP 25-50/2 0.1 0.1 0.2 0.5 - - -
TP 25-80/2 0.1 0.1 0.1 0.3 - - -
TP 25-90/2 0.1 0.1 0.2 0.5 - - -
TP 32-50/2 0.1 0.1 0.1 0.2 - - -
TP 32-80/2 0.1 0.1 0.2 0.5 - - -
TP 32-90/2 0.1 0.1 0.2 0.5 - - -
TP, TPD 32-60/2 0.1 0.1 0.2 1.0 1.5 3.2 -
TP, TPD 32-120/2 0.1 0.2 0.7 1.5 2.0 3.7 -
TP, TPD 32-150/2 0.1 0.3 0.8 1.6 2.1 3.8 -
TP, TPD 32-180/2 0.5 0.7 1.2 2.0 2.5 4.2 -
TP, TPD 32-230/2 0.7 0.9 1.4 2.2 2.7 4.4 -
TP, TPD 32-200/2 0.1 0.1 0.2 0.9 1.5 3.1 -
TP, TPD 32-250/2 0.1 0.1 0.3 1.0 1.6 3.2 -
TP, TPD 32-320/2 0.1 0.1 0.6 1.3 1.9 3.5 -
TP, TPD 32-380/2 0.1 0.2 0.7 1.4 2.0 3.6 -
TP, TPD 32-460/2 0.1 0.2 0.7 1.4 1.9 3.6 -
TP, TPD 32-580/2 0.2 0.4 0.9 1.6 2.2 3.8 -
TP 40-50/2 0.1 0.1 0.1 0.3 - - -
TP 40-80/2 0.1 0.1 0.2 0.5 - - -
TP 40-90/2 0.1 0.1 0.2 0.5 - - -
TP, TPD 40-60/2 0.1 0.1 0.5 1.2 1.8 3.5 -
TP, TPD 40-120/2 0.1 0.1 0.4 1.2 1.7 3.4 -
TP 40-180/2 0.1 0.2 0.7 1.5 2.0 3.7 -
TP, TPD 40-190/2 0.1 0.3 0.8 1.6 2.1 3.8 -
TP, TPD 40-230/2 0.7 0.9 1.4 2.2 2.7 4.4 -
TP, TPD 40-270/2 0.7 0.9 1.4 2.2 2.7 4.4 -
TP, TPD 40-240/2 0.1 0.1 0.4 1.1 1.7 3.3 -
TP, TPD 40-300/2 0.1 0.1 0.4 1.1 1.6 3.3 -
TP, TPD 40-360/2 0.2 0.4 0.9 1.6 2.1 3.8 -
TP, TPD 40-430/2 0.1 0.1 0.5 1.2 1.8 3.4 -
TP, TPD 40-530/2 0.1 0.1 0.6 1.3 1.9 3.5 -
TP, TPD 40-630/2 0.1 0.3 0.8 1.5 2.1 3.7 -
TP, TPD 50-60/2 0.1 0.1 0.4 1.1 1.7 3.4 -
TP, TPD 50-120/2 0.1 0.2 0.7 1.5 2.0 3.7 -
646
Appendix A

Grundfos TP Specifications

General

Motor Efficiency	IE3
Series	TP
Connection Type	Flanged
Protection Class	IP55
Installation	In-line
Material	Stainless Steel
Maximum Operating Pressure	16 bar
Flange Standard	EN 1092
Pump Housing Material	Stainless Steel
Impeller Material	Stainless Steel
Temperature Range	-25 °C to +120 °C
Liquid Temperature Range	-25 °C to +120 °C
