Pump type
(50 Hz)
p [bar]
20 °C 60 °C 90 °C 110 °C 120 °C 140 °C 150 °C
TP, TPD 50-180/2 0.1 0.2 0.7 1.4 2.0 3.7 -
TP, TPD 50-160/2 0.1 0.1 0.1 0.8 1.4 3.0 -
TP, TPD 50-190/2 0.1 0.1 0.1 0.8 1.4 3.0 -
TP, TPD 50-240/2 0.1 0.1 0.1 0.8 1.4 3.0 -
TP, TPD 50-290/2 0.1 0.1 0.2 0.9 1.5 3.1 -
TP, TPD 50-360/2 0.1 0.1 0.2 1.0 1.5 3.1 -
TP, TPD 50-430/2 0.1 0.1 0.4 1.1 1.6 3.3 -
TP, TPD 50-420/2 0.1 0.1 0.3 1.1 1.6 3.2 -
TP, TPD 50-540/2 0.1 0.1 0.5 1.3 1.8 3.4 -
TP, TPD 50-630/2 0.1 0.1 0.6 1.4 1.9 3.6 -
TP, TPD 50-710/2 0.6 0.8 1.3 2.0 2.6 4.2 -
TP, TPD 50-830/2 0.5 0.7 1.2 2.0 2.5 4.1 -
TP, TPD 50-900/2 1.0 1.2 1.7 2.4 3.0 4.6 -
TP, TPD 65-60/2 0.1 0.3 0.8 1.5 2.1 3.8 -
TP, TPD 65-120/2 0.5 0.7 1.2 2.0 2.5 4.2 -
TP, TPD 65-180/2 0.3 0.5 1.0 1.8 2.3 4.0 -
TP, TPD 65-170/2 0.1 0.1 0.1 0.9 1.4 3.1 -
TP, TPD 65-210/2 0.1 0.1 0.2 0.9 1.5 3.1 -
TP, TPD 65-250/2 0.1 0.1 0.3 1.0 1.6 3.2 -
TP, TPD 65-340/2 0.1 0.1 0.2 0.9 1.4 3.1 -
TP, TPD 65-410/2 0.1 0.1 0.2 0.9 1.4 3.1 -
TP, TPD 65-460/2 0.1 0.1 0.2 1.0 1.5 3.1 -
TP, TPD 65-550/2 0.1 0.1 0.3 1.0 1.6 3.2 -
TP, TPD 65-660/2 0.1 0.1 0.4 1.1 1.6 3.3 -
TP, TPD 65-720/2 0.1 0.1 0.6 1.3 1.9 3.5 -
TP, TPD 65-930/2 0.6 0.8 1.3 2.0 2.6 4.2 -
TP, TPD 80-120/2 1.2 1.4 1.9 2.7 3.2 4.9 -
TP, TPD 80-140/2 0.1 0.2 0.7 1.4 1.9 3.6 -
TP, TPD 80-180/2 0.1 0.1 0.3 1.1 1.6 3.2 -
TP, TPD 80-210/2 0.1 0.1 0.4 1.1 1.7 3.3 -
TP, TPD 80-240/2 0.1 0.1 0.5 1.3 1.8 3.4 -
TP, TPD 80-250/2 0.1 0.3 0.8 1.6 2.1 3.7 -
TP, TPD 80-330/2 0.1 0.2 0.7 1.4 2.0 3.6 -
TP, TPD 80-400/2 0.2 0.4 0.9 1.6 2.2 3.8 -
TP, TPD 80-520/2 0.1 0.1 0.6 1.4 1.9 3.5 -
TP, TPD 80-570/2 0.1 0.3 0.8 1.6 2.1 3.7 -
TP, TPD 80-700/2 0.6 0.8 1.3 2.1 2.6 4.2 -
TP, TPD 100-120/2 1.9 2.1 2.6 3.4 3.9 5.6 -
647
Appendix A
