Pump type
(50 Hz)
p [bar]
20 °C 60 °C 90 °C 110 °C 120 °C 140 °C 150 °C
TP, TPD 100-160/2 0.1 0.1 0.6 1.3 1.9 3.5 -
TP, TPD 100-200/2 0.1 0.1 0.4 1.2 1.7 3.3 -
TP, TPD 100-240/2 0.1 0.1 0.5 1.3 1.8 3.4 -
TP, TPD 100-250/2 0.6 0.8 1.3 2.0 2.5 4.2 -
TP, TPD 100-310/2 0.6 0.8 1.3 2.0 2.6 4.2 -
TP, TPD 100-360/2 0.6 0.8 1.3 2.0 2.5 4.2 -
TP, TPD 100-390/2 1.0 1.2 1.7 2.4 3.0 4.6 -
TP, TPD 100-480/2 1.5 1.7 2.2 2.9 3.5 5.1 -
TP 100-530/2 1.6 1.8 2.2 3.2 3.7 5.3 6.6
TP 100-650/2 1.4 1.6 2.0 3.0 3.5 5.1 6.4
TP 100-800/2 1.3 1.5 1.9 2.9 3.4 5.0 6.3
TP 100-950/2 1.3 1.5 1.9 2.9 3.4 5.0 6.3
TP 100-1040/2 1.2 1.4 1.8 2.8 3.3 4.9 6.2
TP 100-1200/2 1.2 1.4 1.8 2.8 3.3 4.9 6.2
TP 100-1410/2 1.2 1.4 1.8 2.8 3.3 4.9 6.2
TP 125-310/2 0.4 0.5 1.0 1.7 2.3 3.9 -
TP 125-360/2 0.5 0.6 1.1 1.8 2.4 4.0 -
A.2. Minimum inlet pressure, 50 Hz, 4-pole
Pump type
(50 Hz)
p [bar]
20 °C 60 °C 90 °C 110 °C 120 °C 140 °C 150 °C
TP, TPD 32-30/4 0.1 0.1 0.1 0.8 1.4 3.1 -
TP, TPD 32-40/4 0.1 0.1 0.1 0.9 1.4 3.1 -
TP, TPD 32-60/4 0.1 0.1 0.3 1.1 1.6 3.3 -
TP, TPD 32-80/4 0.1 0.1 0.1 0.5 1.0 2.7 -
TP, TPD 32-100/4 0.1 0.1 0.1 0.5 1.1 2.7 -
TP, TPD 32-120/4 0.1 0.1 0.1 0.6 1.1 2.7 -
TP, TPD 40-30/4 0.1 0.1 0.2 0.9 1.5 3.2 -
TP 40-60/4 0.1 0.1 0.1 0.8 1.4 3.1 -
TP, TPD 40-90/4 0.1 0.1 0.3 1.0 1.6 3.3 -
TP, TPD 40-100/4 0.1 0.1 0.2 0.9 1.5 3.1 -
TP, TPD 40-110/4 0.1 0.1 0.1 0.6 1.2 2.8 -
TP, TPD 40-140/4 0.1 0.1 0.1 0.7 1.3 2.9 -
TP, TPD 50-30/4 0.1 0.1 0.1 0.9 1.4 3.1 -
TP, TPD 50-60/4 0.1 0.1 0.2 0.9 1.5 3.2 -
TP, TPD 50-90/4 0.1 0.1 0.1 0.6 1.1 2.8 -
TP, TPD 50-80/4 0.1 0.1 0.1 0.8 1.3 3.0 -
648
Appendix A
