Settings
TPE3
TPE3 D
TPE2
TPE2 D
Multipump
system
Section Page
Setpoint 14.2 Setpoint 27
Operating mode 14.3 Operating mode 27
Control mode 14.5 Control mode 28
Date and time 
1)

1)

14.29 Date and time (Set
date and time)
45
Flow limit  -  14.6 FLOWLIMIT 33
Automatic Night Setback  - 
14.7 Automatic Night
Setback
33
Temperature influence  -  14.19 Temperature influence 42
Buttons on product 
14.31 Buttons on product
(Enable/disable settings)
45
Controller 
14.15 Controller (Controller
settings)
38
Operating range 14.16 Operating range 39
Ramps -  14.22 Ramps 44
Pump number -
14.26 Number (Pump
number)
44
Radio communication -
14.27 Radio communication
(Enable/disable radio
comm.)
45
Analog input 1 -
14.8 Analog inputs 33Analog input 2 -
Analog input 3 
1)

1)
-
Built-in Grundfos sensor  - 
14.9 Built-in Grundfos
sensor
34
Pt100/1000 input 1 
1)

1)
-
14.10 Pt100/1000 inputs 35
Pt100/1000 input 2 
1)

1)
-
Digital input 1 -
14.11 Digital inputs 35
Digital input 2 
1)

1)
-
Digital in/output 3 -
14.12 Digital inputs/outputs 36
Digital in/output 4 
1)

1)
-
Predefined setpoint 
1)

1)

1)
14.18 Predefined setpoints 42
Analog output 
1)

1)
- 14.14 Analog output 37
External setpoint funct.  -
14.17 External setpoint
function
39
Signal relay 1  -
14.13 Signal relays 1 and 2
(Relay outputs)
36
Signal relay 2  -
Limit 1 exceeded - 
14.20 Limit-exceeded
function
43
Limit 2 exceeded - 
Alternating operation, time - - 
2)
14.47 Multipump setup
(Setup of multi-pump
system)
48
Time for pump changeover - - 
1) + 2)
Standstill heating - 14.23 Standstill heating 44
Motor bearing monitoring  -
14.24 Motor bearing
monitoring
44
Service - 14.25 Service 44
Store settings  -
14.35 Store settings (Store
actual settings)
46
Recall settings -
14.36 Recall settings (Recall
stored settings)
46
Undo 14.37 Undo 46
Pump name 14.38 Pump name 46
Connection code 14.39 Connection code 46
Unit configuration 
14.30 Unit configuration
(Units)
45
1)
Only available if an advanced functional module, FM 300, is fitted.
2)
Only available if Grundfos GO is connected to a multipump system.
