Grundfos TPE 2 Series User Manual

English (GB)
37
14.14 Analog output
Whether the analog output is available or not, depends on the
functional module fitted in the pump:
* See section 22. Identifying the functional module.
The analog output enables the transfer of certain operating data
to external control systems.
To set the analog output, make the settings below.
Output signal
• 0-10 V
• 0-20 mA
• 4-20 mA.
Function of analog output
• Actual speed
the reading is a percentage of nominal speed.
• Actual value
The reading is a percentage of the range between sensor
min
and
sensor
max
.
• Resulting setpoint
The reading is a percentage of the external setpoint range.
• Motor load
Reading is a percentage of the range between 0 and 200 % of the
maximum permissible load at the actual speed.
• Motor current
The reading is a percentage of the range between 0 % and 200 %
of the rated current (I
N
).
• Limit 1 exceeded and Limit 2 exceeded
This function is only available on TPE2, TPE2 D pumps.
Limit-exceeded function is typically used for monitoring of
secondary parameters in the system. If the limit is exceeded, an
output, warning or alarm is activated.
•Flow rate
The reading is a percentage of the range between 0 and 200 % of
the nominal flow (Q
nom
).
Factory setting
See section 31. Factory settings.
Function (terminal)
FM 200*
(standard)
FM 300*
(advanced)
Analog output - 
Signal range
[V, mA]
Actual speed
[%]
0100200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA
Signal range
[V, mA]
Actual value
Sensor
min
Sensor
max
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal range
[V, mA]
Resulting setpoint
[%]
0100
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal range
[V, mA]
Motor load
[%]
0100200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA
Signal range
[V, mA]
Motor current
[%]
0 100 200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA
Signal range
[V, mA]
Limit-exceeded function
Output not active Output active
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal range
[V, mA]
Flow rate
[%]
0 100 200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA

Grundfos TPE 2 Series Specifications

General

Enclosure Class	IP55
Frequency	50/60 Hz
Protection Class	IP55
Pump Type	Centrifugal
Pressure Rating	10 bar
Material	Stainless Steel
Operating Pressure	10 bar
Control Mode	Variable Speed
Communication	Modbus
Impeller Type	Closed Impeller
