English (GB)
62
26. Megging
27. Technical data, single-phase motors
27.1 Supply voltage
• 1 x 200-240 V - 10 %/+ 10 %, 50/60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
Recommended fuse size
Standard as well as quick-blow or slow-blow fuses may be used.
27.2 Leakage current
Earth leakage current less than 3.5 mA (AC supply).
Earth leakage current less than 10 mA (DC supply).
The leakage currents are measured in accordance with EN
61800-5-1:2007.
28. Technical data, three-phase motors
28.1 Supply voltage
• 3 x 380-500 V - 10 %/+ 10 %, 50/60 Hz, PE.
Check that the supply voltage and frequency correspond to the
values stated on the nameplate.
Recommended fuse size
Standard as well as quick-blow or slow-blow fuses may be used.
28.2 Leakage current
The leakage currents are measured in accordance with EN
61800-5-1:2007.
29. Inputs or outputs
Earth reference (GND)
All voltages refer to GND.
All currents return to GND.
Absolute maximum voltage and current limits
Exceeding the following electrical limits may result in severely
reduced operating reliability and motor life:
Relay 1:
Maximum contact load: 250 VAC, 2 A or 30 VDC, 2 A.
Relay 2:
Maximum contact load: 30 VDC, 2 A.
GENI terminals: -5.5 to 9.0 VDC or < 25 mADC.
Other input or output terminals: -0.5 to 26 VDC or < 15 mADC.
Digital inputs (DI)
Internal pull-up current > 10 mA at V
i
= 0 VDC.
Internal pull-up to 5 VDC (currentless for V
i
> 5 VDC).
Certain low logic level: V
i
< 1.5 VDC.
Certain high logic level: V
i
> 3.0 VDC.
Hysteresis: No.
Screened cable: 0.5 - 1.5 mm
2
/ 28-16 AWG.
Maximum cable length: 500 m.
Open-collector digital outputs (OC)
Current sinking capability: 75 mADC, no current sourcing.
Load types: Resistive or/and inductive.
Low-state output voltage at 75 mADC: Max. 1.2 VDC.
Low-state output voltage at 10 mADC: Max. 0.6 VDC.
Overcurrent protection: Yes.
Screened cable: 0.5 - 1.5 mm
2
/ 28-16 AWG.
Maximum cable length: 500 m.
Analog inputs (AI)
Voltage signals:
• 0.5 - 3.5 VDC, AL AU.
• 0-5 VDC, AU.
• 0-10 VDC, AU.
Voltage signal: R
i
> 100 kΩ at 25 °C.
Leak currents may occur at high operating temperatures. Keep
the source impedance low.
Current signal ranges:
• 0-20 mADC, AU.
• 4-20 mADC, AL AU.
Current signal: R
i
= 292 Ω.
Current overload protection: Yes. Change to voltage signal.
Measurement tolerance: - 0/+ 3 % of full scale (max.-point
coverage).
Screened cable: 0.5 - 1.5 mm
2
/ 28-16 AWG.
Maximum cable length: 500 m (excl. potentiometer).
Potentiometer connected to +5 V, GND, any AI:
Use maximum 10 kΩ.
Maximum cable length: 100 m.
Megging of an installation incorporating MGE motors
is not allowed, as the built-in electronics may be
damaged.
Motor size
[kW]
Min.
[A]
Max.
[A]
0.25 - 0.75 6 10
1.1 - 1.5 10 16
Motor size
[kW]
Min.
[A]
Max.
[A]
0.25 - 1.1 6 6
1.5 - 2.2 6 10
Motor size
[kW]
Leakage current
[mA]
0.75 - 2.2
supply voltage less than 400 V
< 3.5
0.75 - 2.2
supply voltage greater than 400 V
< 5
