GSE 375 - Discharge

43
Parameter Setting Actual Cutoff Value Comments
Start 1 = [TARE] Start water with [TARE].
Target 2 = 15,000 Desired corn syrup weight.
Pre-Act 2 = 236 15,000 – 236 = 14,764
Corn syrup valve closes at 14,764 lbs. Free-fall will bring weight
to 15,000.
Learn 2 = Enabled Analyze previous five fills and auto-adjust pre-act 2.
Start 2 = Auto
Calculated cutoff value for corn
syrup is added to current
displayed weight
Start corn syrup when water is done and motion has stopped.
Target 3 = 5,000 Desired caramel coloring weight.
Pre-Act 3 = 142 5,000 – 142 = 4,858
Carmel coloring valve closes at 4,858. Free-fall will bring weight
to 5,000.
Learn 3 = Enabled Analyze previous five fills and auto-adjust pre-act 3.
Start 3 = Auto
Calculated cutoff value for
carmel coloring is added to
current displayed weight
Start caramel coloring when corn syrup is done and motion has
ceased.
Pause = Keypad Keypress will pause batch operation.
DISCHARGE
The discharge program is designed for single-speed or dual-speed dispensing of product from a
larger weigh vessel. Discharge is a loss-in-weight application similar in operation to the fill
program. When a discharge is initiated, the scale automatically tares and comes to a net zero
weight. The appropriate setpoints are activated and material is discharged until the decreasing
net weight reaches the desired target value.
Table 3-8: Setpoint Setup (Discharge)
Setpoint Selection Function Description
P5100.1 Discharge Select discharge setpoint operation.
P5101.-- Targ1 Final dispensed target value.
P5104.0 Based Select between net or count (quantity)
P5105.-- PA 1 Pre-act 1 value (fast-to-slow value; 0 for single-speed).
P5107.0 Start 1 Setpoint activation method.
P5109.-- PA 2 Pre-act 2 value (final cutoff).
P5110.1 Learn 2 Learn feature for pre-act 2.
P5114.1 PrAc 1 Pre-act 1 available as subset in Weigh Mode.
P5115.1 PrAc 2 Pre-act 2 available as subset in Weigh Mode.
P5116.1 Pause Keypress invokes pause.
See Key-In Parameters on page 18 for instructions on using the front panel keys for entering
data.
Activation Method (Discharge)
The dispensing activation is limited to [TARE] or a remote key input. The deactivation of the
setpoints is automatic. The desired target may be based on net or quantity (if counting is
enabled). See Activation Methods (General) on page 37 for activation details.
Discharge Status Annunciator Status Setpoint Status (Requires Setpoint Option Board)
Fast Discharge SP 1 & SP 2 Illuminated Relay 1 and 2 Contacts Closed
Slow (or Single-Speed)
Discharge
SP 1 Illuminated Relay 1 Contacts Closed
Fill Done or Pause SP 1 & 2 Off Relay 1 and 2 Contacts Open
