FYI
If time out is enabled (P270), then the transmit should be set for continuous at P210 or
P230 and have stability disabled at P212 or P232
Example:
The master unit will be active and the Net weight will be displayed on the remote unit. The net
and lb annunciators will illuminate. The codes for the annunciators will be entered as they are
control codes (see Entering ASCII Control Codes on page 32). The address of the remote unit at
P272 is 4. If P272 is set to None!, do not enter anything for the address field.
Access custom transmit 1 (P1000) or custom transmit 2 (P2000).
Format String:
If P274 and P275 = 1 - 255
<Start Character>, <Address>, <Annunciator 1>, <Annunciator 2>, <Parameter>, <End
Character>
~or~
If P274 or P275 = 0
<Address>, <Annunciator 1>, <Annunciator 2>, <Parameter>, <Line Feed>
Custom Transmit :
1. .002 [SAMPLE/Enter] or [TARE] - <Start Character>
2. .004 [SAMPLE/Enter] or [TARE] - <Address>
3. .016 [SAMPLE/Enter] or [TARE] - <Annunciator 1>
4. .064 [SAMPLE/Enter] or [TARE] <Annunciator 2>
5. [SAMPLE/Enter] or [TARE], 1, [SAMPLE/Enter] or [TARE], 160, [SAMPLE/Enter] or
[TARE] - <Net Parameter>
6. .003 [SAMPLE/Enter] or [TARE] - <End Character>
7. Save changes and exit the setup mode.
Table 3-16: Annunciator Choices
ASCII Code
128 64 32 16 8 4 2 0
Annunciator 1 Good2 Gross Net Qty Other kg
Annunciator 2 lb Spt 1 Spt 2 Spt 3  0  Motion
The start character and end character can be any ASCII character 1 - 255. Refer to Table 3-16
for the annunciator codes to be entered in the custom transmit. Always use 160 for the format
code when entering a parameter.
ACCESS THE SETUP MODE FROM THE REMOTE DISPLAY MODE
If the Model 370/375 is set for remote display, unplug the unit and press [ZERO] + [SELECT]
upon power up. Follow the instructions below to access the setup mode.
