FALSE ZERO
False Zero calibrates the Model 370/375 without removing the current gross weight. This is
particularly useful in tank weighing applications where it may be both time consuming and costly
to completely empty the tank. This operation is achieved by establishing a false (temporary zero)
zero reference. Test weights may then be added to verify calibration. The zero reference
determined during the last calibration is not affected.
False
Zero Calibration Without Removing Existing Load Example (370):
1. Press [ZERO] + [SELECT].
DISPLAY READS  Setup
2. Press [ZERO] [PRINT] [UNITS] [TARE].
DISPLAY READS  Fast ~ Cal~First ~ Zero? ~ 5075.
3. Press [SELECT] [SELECT].
DISPLAY READS  False ~ Zero? ~5075.
4. Press [TARE] to establish false (temporary) zero.
DISPLAY READS  Units ~ =lb
5. Pause to display calibration units.
DISPLAY READS  Enter ~ Load? ~ 00.
6. Place a 2500lb test weight on scale.
DISPLAY READS  Enter ~ Load? ~ 2510.
7. Enter 2500.
DISPLAY READS  2500
8. Press [TARE] to establish span.
DISPLAY READS  2500.
9. Pause for motion delay.
DISPLAY READS  Cal ~ Good? ~ 2500.
10. Press [TARE] to accept calibration.
DISPLAY READS  Enter ~ =Stor
11. Press [TARE] to save calibration.
DISPLAY READS  Enter ~ =End
12. Press [TARE] to exit calibration.
DISPLAY READS  5055.
13. Remove the calibration weight.
DISPLAY READS  00.
False Zero Calibration Without Removing Existing Load Example (375):
1. Press 100 [SELECT].
DISPLAY READS  Setup
2. Press 54321 [SAMPLE/Enter].
DISPLAY READS  Fast ~ Cal~First ~ Zero? ~ 5075.
3. Press [SELECT] [SELECT].
DISPLAY READS  False ~ Zero? ~5075.
4. Press [SAMPLE/Enter] to establish false (temporary) zero.
DISPLAY READS  Units ~ =lb
5. Pause to display calibration units.
DISPLAY READS  Enter ~ Load? ~ 00.
6. Place a 2500lb test weight on scale.
DISPLAY READS  Enter ~ Load? ~ 2510.
