79
2.5 V
8. Press [SAMPLE/Enter] to increase the output to 50%.
0-20A ~ 50P
5 V
9. Press [SAMPLE/Enter] to increase the output to 75%.
0-20A ~ 75P
7.5 V
10. Press [SAMPLE/Enter] to increase the output to 100%.
0-20A ~ 100P
10 V
To test the 4-20mA output mode:

Voltmeter readings are based on the use of a 500 ohm precision resistor. Caution! Do not exceed
500 ohms.
1. Enter the Setup Mode (see Setup Mode on page 15).
Chngs Poss!
P110.-- ~ F.S.= ~ 100.00
2. Attach the voltmeter + (red) lead to pin 3 (0-10VDC) and the - (black) lead to pin 2
(ISOLATED GND) of the Analog Output connector.
3. Key in 62004 [SELECT].
Test ~ 4-20A
Per P176
4. Press [SAMPLE/Enter] to set the output to 0%.
4-20A ~ 0P
2 V
5. Press [SAMPLE/Enter] to increase the output to 25%.
4-20A ~ 25P
4 V
6. Press [SAMPLE/Enter] to increase the output to 50%.
4-20A ~ 50P
6 V
7. Press [SAMPLE/Enter] to increase the output to 75%.
4-20A ~ 75P
8 V
8. Press [SAMPLE/Enter] to increase the output to 100%.
4-20A ~ 100P
10 V
