DA98A AC Servo Drive Unit
User Manual
1.2 Reception check
1) Check the following items after delivery:
（1） Whether the packaging box is well or goods are damaged during transportation.
（2） Whether the AC servo drive unit, servo motor nameplates are consistent with the
ordered ones.
（3） Whether the accessories completely conforms to the packing list.
2
Note
z Do not install the servo drive unit which is damaged or lacks of
components.
z The AC servo drive unit must be used with the suited servo motor.
z Please contact with us or suppliers if there are any questions after
receiving goods.
2） Model signification：
（1） Model for AC servo drive unit
DA98A-10-110SJT-M040D
Suited servo motor model（GSK SJT series） 1※
Output power：2 digits (04,06…23) corresponding to 0.4~2.3KW 2※
Series code
※ 1：It can be matched with other domestic or imported servo motor which is needed to be
ordered. This drive unit default parameters are only suitable for SJT, STZ, Star series servo
motor. And the factory set parameters for other servo motors have been backup in the
EEPROM area. Backup recovery but default recovery operation should be performed when
the factory set parameters are to be recovered.
