DA98A AC Servo Drive Unit
User Manual
CHAPTER 2 INSTALLATION
z Storage and installation for this unit must be complied to the environmental
requirement.
z Do not put the products into a pile to protect from being damaged or fallen down.
z Original packaging should be employed for products storage and delivery.
z Products which are damaged or shorten of parts must not be used.
z Fireproofing material should be used for the products installation and they should
not be installed on or near flammable objects.
z Servo drive unit should be installed into cabinet to prevent dust, corrosive air, liquid,
conductors and inflammable substances from entering it.
z The servo drive unit and motor should be protected from vibration and shock.
z The dragging of motor wire, motor shaft and encoder is unallowed.
Note
2.1 Environmental condition
Item DA98A AC servo drive unit GSK SJT series servo motor
Usage temperature/
humidity
0～+40℃（no icing）
below 95%RH（no condensation）
-10～+40℃（no icing）
below 90%RH（no condensation）
Storage/transport
temperature/humidity
-40～55℃
95%RH（no condensation）
-40～+55℃
below 80%RH（no condensation）
Atmosphere
environment
No corrosive gas，flammable gas,
oil fog or dust in cabinet
No corrosive gas，flammable gas, oil
fog or dust inside house(no insolation)
Altitude
Altitude: below 1000m Altitude: below 1000m
Vibration
Less than 0.5G（4.9m/s
2
）10-60HZ（non-continuous run）
Protection degree
IP43 IP65
2.2 Installation of AC servo drive unit
z It must be installed in a well protected cabinet.
z It must be installed by the specified direction and interval to get a good heat
rediating.
z To fix the unit on or near flammable objects that fire may occur is unallowed.
Note
