DA98A AC Servo Drive Unit
User Manual
25
4.2 Parameter function
Table 4.2 Parameter function
No. Name Function
Parameter
range
0 Password
① It is used for parameter to be modified by mistake. Usually
set this parameter for a required password and then set the
parameter to be modified. After debugging, set this
parameter for 0 to ensure it not to be modified by mistake
later.
② The password is classified into several levels which
correspond to user parameter, system parameter and all the
other parameters.
③ Use the model password to modify model parameter (No.1)
and the model parameter can’t be modified by other
password.
④ The user password is 315.
⑤ The drive unit model password is 385.
0~9999
1 Model code
① It corresponds to the AC servo drive unit and motor with
different power level in the same series.
② Different models correspond to different parameter default
value. Ensure the parameter is right when using default
parameter recovery function.
③ This parameter should be set again after reparation for
EEPROM alarm (No.20), then recover the default
parameter. Or else the drive unit may act abnormally or be
damaged.
④ First set the password(parameter No. 0) for 385, then
modify this parameter.
⑤ Refer to this chapter for the parameters significance.
0~69
2
Software version
(read-only)
Software version can be viewed but cannot be modified. *
