DA98A AC Servo Drive Unit
User Manual
26
3 Initial display state
Select display state after the AC servo drive unit is
powered on.
0：Motor speed display;
1：Current position lower 5-bit display;
2：Current position higher 5-bit display;
3：Position instruction (instruction pulse accumulation ) lower
5-bit display;
4：Position instruction (instruction pulse accumulation ) higher
5-bit display;
5：Position error lower 5-bit display;
6：Position error higher 5-bit display;
7：Motor torque display;
8：Motor current display;
9：Linear speed display;
10：Control mode display;
11：Position instruction pulse frequency display;
12：Speed instruction display;
13：Torque instruction display;
14：Rotor absolute position display in one revolution;
15：Input terminal state display;
16：Output terminal state display;
17：Encoder input signal display;
18：Running state display;
19：Alarm code display;
20：Reserved.
0~20
4
Control mode
selection
Set control mode of drive unit by this parameter:
0：Position control mode;
1: Speed control mode
2：Trial run control mode;
3：JOG control mode;
4：Encoder zeroing mode;
5：Open loop mode(for motor and encoder test)
① Position control mode Position instruction is input from
the pulse input interface.
② Speed control mode Speed instruction is input from the
input terminal. The internal speed is selected by the
combination of SC1 and SC2.
SC1 OFF，SC2 OFF ：internal speed 1
SC1 ON，SC2 OFF ：internal speed 2
SC1 OFF，SC2 ON ：internal speed 3
SC1 ON，SC2 ON ：internal speed 4
③ Trial run control mode Speed instruction is input from the
keyboard, which is used for drive unit and servo motor test.
④ JOG control mode In this mode, pressing down ↑ key and
holding it on, the motor runs by JOG speed, releasing the
key, the motor stops and keeps zero speed; pressing down
↓ key and holding it on, the motor runs reversely by JOG
speed; releasing the key, the motor stops and keeps zero
speed.
⑤ Encoder zeroing mode It is used for encoder factory
zeroing adjustment of motor.
0~5
